15.3.9 Application warning mask
The Application Warning mask signals via a digital signal if an afore configured warn-
ing applies. The configuration of the Application Warning mask is carried out via Cre-
ate Appl. Warning Mask
626.
As soon as limit switches are reached or contouring error limit
s are exceeded, a
warning can be issued. The warnings refer to the parameter values set in er-
ror/warning behavior. Depending on the application, any number of warnings can be
configured. This enables internal and/or external control using a common output
signal. The display of Warning Application 273 is not affected by the Warning mask.
Create Appl. Warning Mask 626
Function
0 -
no change
The configured warning mask is not changed.
2 - Activate all Warnings
The warnings reports stated are linked in the
warning mask.
10 - Warning V-belt
The Operation mode 581 for V-belt monitoring
signals no-load operation of the application.
11 -
Warning pos. SW-Limit-
Switch
1)
Warning message indicating that the positive
SW limit switch has been reached (parameter
Positive SW limit switch
1145).
12 -
Warning neg. SW-Limit-
Switch
1)
Warning message indicating that the negative
SW limit switch has been reached (parameter
Negative SW limit switch 1146).
13 -
Warning pos. HW-Limit-
Switch
1)
Warning message indicating that the positive
HW limit switch has been reached.
14 -
Warning neg. HW-Limit-
Switch
1)
Warning message indicating that the negative
HW limit switch has been reached.
15 - Warning Contouring Error
1)
Warning message, indicating that the contour-
ing error monitoring range adjusted with pa-
rameter
Warning Threshold 1105 has been
left.
16 - Warning Encoder
An encoder with data track can trigger a warn-
ing.
Selection is not effective with encoders
without data track.
17 - Warning User 1
The signal set on digital input User Warning 1
1363 is active.
18 - Warning User 2
The signal set on digital input User Warning 2
1364 is active.
102 -
Deactivate all Warnings
All warnings are deactivated.
110 -
Deactivate Warning V-Belt
Warning 10 is deactivated.
111 -
Deactivate Warning pos.
SW-Limit-Switch
Warning 11 is deactivated.
112 -
Deactivate Warning neg.
SW-Limit-Switch
Warning 12 is deactivated.
113 -
Deactivate Warning pos.
HW-Limit-Switch
Warning 13 is deactivated.
114 -
Deactivate Warning neg.
HW-Limit-Switch
Warning 14 is deactivated.
115 -
Deactivate Warning Contour-
ing Error
Warning 15 is deactivated.
116 -
Deactivate Warning Encoder
Warning 16 is deactivated.
117 -
Deactivate Warning User 1
Warning 17 is deactivated.
118 -
Deactivate Warning User 2
Warning 18 is deactivated.
1)
Refer to the application manual “Positioning” for further details.
190 Operating Instructions ACU 06/13
