13.1 Overload Ixt
The admissible load behavior depends on various technical data of the frequency
inverters and the ambient conditions.
The selected Switching frequency 400
defines the rated current and the available
overload for one second and sixty seconds, respectively. The Warning Limi
t Short
Term Ixt 405 and Warning Limit Long Term Ixt 406 are to be parameterized ac-
cordingly.
Parameter
Settings
No. Description Min. Max. Fact. sett.
405 Warning Limit Short Term Ixt 6 % 100 % 80 %
406 Warning Limit Long Term Ixt 6 % 100 % 80 %
Exceeding of warning limit is signaled by 165 - Warning Ixt”.
Output signals
Digital signals indicate the attainment of warning limits.
165 -
Warning Ixt
1)
Warning Limit Short Term Ixt 405 or Warning Limit
Long Term Ixt 406 is attained.
7 -
Ixt-Warning
2)
1)
For linking with inverter functions
2)
For digital output
13.2 Temperature
The ambient conditions and the energy dissipation at the current operating point
result in the frequency inverter heating up. In order to avoid a fault switch-
off of the
frequency inverter, the Warning Limit Heat Sink Temp.407 for the heat sink temper-
ature limit and the
Warning Limit Inside Temp. 408 as an internal tempe
rature limit
are to be parameterized. The temperature value at which a warning message is out-
put is calculated from the type-dependent temperature li
mit minus the adjusted
warning limit.
The switch-
off limit of the frequency inverter for the maximum temperature is an
internal temperature of 65 °C and a heat sink temperature of 80 °C – 90 °C.
Parameter
Settings
No.
Description
Min.
Max.
Fact. sett.
407
Warning Limit Heat Sink Temp.
-25 °C
0 °C
-5 °C
408
Warning Limit Inside Temp.
-25 °C
0 °C
-5 °C
Minimum temperatures are defined as -10 °C (interior) and 30 °C (heat sink tempera-
ture.
Output signals
Digital signals indicate the attainment of warning limits.
166 -
Warning Heat Sink
Temperature
1)
The value “80 °C minus Warning Limit Heat Sink
Temp.
407” is attained.
8 -
2)
167 -
Warning Inside
Temperature
1)
The value “65 °C minus Warning Limit Inside Temp.
408” is attained.
9 -
2)
170 -
Warning Over-
temperature
1)
The value
− “80 °C minus Warning Limit Heat Sink Temp.
407” or
− “65 °C minus
Warning Limit Inside Temp. 408”
is attained.
12 -
2)
1)
For linking with inverter functions
2)
For digital output
150 Operating Instructions ACU 06/13
