8.4 Speed sensor
For some configurations an incremental speed sensor must be connected. Dependent
on the speed sensor type it can be connected to the basic device or to an expansion
module. Some applications require the connection to the basic device as well as to the
expansion module.
The source of the actual speed value is selected via parameter Actual Speed
Source
766. By default, speed sensor 1 is used as the actual speed source.
If speed
sensor 2 of an expansion module delivers the actual value signal for the speed control-
ler, speed sensor 2 must be selected as the source.
Actual Speed Source 766
Function
1 - Speed Sensor 1
The actual speed source is speed sensor 1 of the
basic device (factory setting).
2 - Speed Sensor 2
The actual speed source is speed sensor 2 of an
expansion module.
1)
1)
Only available if an expansion module is installed.
Dependent on the application and applied speed sensors the settings of parameters
must be adapted according to the following table.
Parameter Only
speed sensor 1
Only
speed sensor 2
Both
speed sensors
490
Operation Mode
speed sensor 1
> 0
0 - Off
> 0
491
Division Marks
speed sensor 1
1…8192
X
1…8192
493
Operation Mode
speed sensor 2
0 - Off
> 0
> 0
494
Division Marks
speed sensor 2
X
1…8192
1…8192
495
Level
X
Selection
Selection
766
Actual Speed Source
1
2
1 or 2
X: can be set to any value, it is not evaluated
The above-mentioned parameters
are selectable dependent on configuration setting
and installed expansion module.
Some applications require two speed sensors. Parameter Actual Speed Source 766
must be set to the motor speed sensor for motor control. The other speed sensor is
used
external. Comply with the application manuals “Electronic gear” and “Positioning”.
114 Operating Instructions ACU 06/13
