BONFIGLIOLI ACTIVE Cube ACU 401-18 User Manual

Operation mode 530,532,554
Function
63 -
Motion-Block Digital Sig-
nal 2
2)
Message on status of a travel order during a
positioning operation. The conditions set for pa-
rameter
Digital Signal 2 1219 were fulfilled.
“Start”, “Reference value reached” and “End”
of a
travel order were evaluated.
64 -
Motion-Block Digital Sig-
nal 3
2)
Message on status of a travel order during a
positioning operation. The conditions set for pa-
rameter
Digital Signal 3 1247 were fulfilled.
“Start”, “Reference value reached” and “End”
of a
travel order were evaluated.
65 -
Motion-Block Digital Sig-
nal 4
2)
Message on status of a travel order during a
positioning operation. The conditions set for pa-
rameter
Digital Signal 4 1248 were fulfilled.
“Start”, “Reference value reached” and “End”
of a
travel order were evaluated.
80 - FT-Output Buffer 1
3)
The output signal of a function table instruction.
The output signal is the signal source „2401 - FT-
Output buffer 1“. The signal source contains the
value of the FT-instruction output, which is as-
signed to the signal source 2401. The assignment
is done by parameter
FT-target output 1 1350
or
FT-target output 2 1351.
81 - FT-Output Buffer 2
3)
The output signal of a function table instruction.
The output signal is the signal source „2402 - FT-
Output buffer 2“. The signal source contains the
value of the FT-instruction output, which is as-
signed to the signal source 2402. The assignment
is done by parameter
FT-target output 1 1350
or
FT-target output 2
1351.
82 - FT-Output Buffer 3
3)
The output signal of a function table instruction.
The output signal is the signal source „2403 - FT-
Output buffer 3“. The signal source contains the
value of the FT-instruction output, which is as-
signed to the signal source 2403. The assignment
is done by parameter
FT-target output 1 1350
or
FT-target output 2 1351.
83 - FT-Output Buffer 4
3)
The output signal of a function table instruction.
The output signal is the signal source „2404 - FT-
Output buffer 4“. The signal source contains the
value of the FT-instruction output, which is as-
signed to the signal source 2404. The assignment
is done by parameter
FT-target output 1 1350
or
FT-target output 2 1351.
90
to
94
Obj 0x3003 DigOut 1
4)
to
Obj 0x3003 DigOut 5
Sources of CAN-objects. For communication
module CM with CAN interface necessary.
100 to 194 Operation modes inverted (LOW active)
1)
Refer to the application manual “Electronic gear” for further details.
2)
Refer to the application manual “Positioning” for further details.
3)
Refer to the application manual “Function table” for further details.
4)
Refer to the operating instructions of the expansion module with CAN interface.
