BONFIGLIOLI ACTIVE Cube ACU 401-18 User Manual

Current Controller
No.
Description
Unit
Setting range
Chapter
700 Amplification - 0.00 ... 8.00
17.5.1
701
Integral time
ms
0.00 ... 10.00
17.5.1
Further motor parameters
713
Magnetizing current 50% flux
%
1 ... 50
10.2.3
714 Magnetizing current 80% flux % 1 ... 80
10.2.3
715 Magnetizing current 110% flux % 110 ... 197
10.2.3
716
Rated magnetizing current
A
0.01⋅I
FIN
... o⋅I
FIN
10.2.3
Field Controller
717 Reference Flux % 0.01 ... 300.00
17.5.6
Further motor parameters
718
Rated slip correction factor
%
0.01 ... 300.00
10.2.4
Frequency Limits
719
Slip Frequency
%
0 ... 10000
14.2
Speed controller
720 Operation mode - Selection
17.5.4
721 Amplification 1 - 0.00 ... 200.00
17.5.4
722
Integral time 1
ms
0 ... 60000
17.5.4
723
Amplification 2
-
0.00 ... 200.00
17.5.4
724
Integral time 2
ms
0 ... 60000
17.5.4
Acceleration Pre-Control
725 Operation mode - Selection
17.5.5
726
Minimum acceleration
Hz/s
0.1 ... 6500.0
17.5.5
727
Mech. time constant
ms
1 ... 60000
17.5.5
Speed controller
728 Current Limit A
0.0 ... o ⋅ I
FIN
17.5.4.1
729
Current limit generator operation
A
-0.1 ... o ⋅ I
FIN
17.5.4.1
730
Torque limit
%
0.00 ... 650.00
17.5.4.1
731
Torque limit generator operation
%
0.00 ... 650.00
17.5.4.1
732
P comp. torque upper limit
%
0.00 ... 650.00
17.5.4.1
733
P comp. torque lower limit
%
0.00 ... 650.00
17.5.4.1
Speed controller
734
Isq limit source motor operation
-
Selection
17.5.4.2
735
Isq limit source gen. operation
-
Selection
17.5.4.2
736
Torque limit source motor operation
-
Selection
17.5.4.2
737 Torque limit source gen. operation - Selection
17.5.4.2
738 Speed control switch-over limit Hz 0.00 ... 999.99
17.5.4
739
Power Limit
kW
0.00 ... 2⋅o⋅P
FIN
17.5.4.1
740
Power limit generator operation
kW
0.00 ... 2⋅o⋅P
FIN
17.5.4.1
Field Controller
741 Amplification - 0.0 ... 100.0
17.5.6
742
Integral time
ms
0.0 ... 1000.0
17.5.6
743
Ref. Isd upper limit
A
0 ... o⋅I
FIN
17.5.6.1
744
Ref. Isd lower limit
A
-I
FIN
... I
FIN
17.5.6.1
Speed controller
748 Backlash damping % 0 ... 300
17.5.4
Modulation Controller
750
Reference modulator
%
3.00 ... 105.00
17.5.7
752 Integral time ms 0.0 ... 1000.00
17.5.7
284 Operating Instructions ACU 06/13
