AS 35_ 5.11 548 270 16.3 640 3690 274 340 10.3 900 4500
79
AS 35_ 6.22 450 270 13.4 850 4060 225 340 8.4 1050 4950
AS 35_ 6.93 404 270 12.0 910 4260 202 340 7.6 1140 5200
AS 35_ 7.51 373 270 11.1 830 4330 186 340 7.0 1050 5280
AS 35_ 7.78 360 270 10.7 960 4490 180 340 6.7 1200 5480
AS 35_ 9.14 306 320 10.8 850 4460 153 400 6.7 1100 5460
AS 35_ 10.18 275 320 9.7 910 4690 138 400 6.1 1150 5740
AS 35_ 11.43 245 320 8.6 960 4940 122 400 5.4 1150 6050
AS 35_ 12.62 222 360 8.8 660 4800 111 400 4.9 1050 6160
AS 35_ 15.37 182 360 7.2 880 5290 91 400 4.0 1150 6750
AS 35_ 17.11 164 360 6.5 940 5560 82 400 3.6 1150 7070
AS 35_ 19.21 146 360 5.8 990 5850 73 400 3.2 1150 7200
AS 35_ 24.19 116 480 6.1 370 5600 58 480 3.1 1150 7200
AS 35_ 29.45 95 480 5.0 700 6190 48 480 2.5 1150 7200
AS 35_ 32.8 85 480 4.5 860 6530 43 480 2.3 1150 7200
AS 35_ 36.82 76 480 4.0 920 6890 38 480 2.0 1150 7200
AS 35 D_ 41.2 68 480 3.7 700 7200 34 480 1.8 830 7200
AS 35 D_ 46.2 61 480 3.3 750 7200 30 480 1.6 830 7200
AS 35 D_ 54.0 52 480 2.8 650 7200 25.9 480 1.4 830 7200
AS 35 D_ 65.8 43 480 2.3 750 7200 21.3 480 1.2 830 7200
AS 35 D_ 73.6 38 480 2.1 830 7200 19.0 480 1.0 830 7200
AS 35 D_ 82.2 34 480 1.8 830 7200 17.0 480 0.92 830 7200
AS 35 D_ 99.3 28.2 480 1.5 750 7200 14.1 480 0.76 830 7200
AS 35 D_ 120.9 23.2 480 1.3 830 7200 11.6 480 0.63 830 7200
AS 35 D_ 134.7 20.8 480 1.1 830 7200 10.4 480 0.56 830 7200
AS 35 D_ 151.1 18.5 480 1.0 830 7200 9.3 480 0.50 830 7200
AS 35
530 Nm
i
n
1
= 2800 min
-1
n
1
= 1400 min
-1
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
2
min
-1
M
n2
Nm
P
n1
kW
R
n1
N
R
n2
N
n
1
= 900 min
-1
n
1
= 500 min
-1
AS 35_ 5.11 176 480 9.3 590 4610 98 530 5.7 1110 5740
79
AS 35_ 6.22 145 480 7.6 1060 5150 80 530 4.7 1160 6380
AS 35_ 6.93 130 480 6.9 1160 5450 72 530 4.2 1160 6730
AS 35_ 7.51 120 480 6.3 970 5510 67 530 3.9 1160 6810
AS 35_ 7.78 116 480 6.1 1160 5770 64 530 3.8 1160 7110
AS 35_ 9.14 98 480 5.2 1160 6100 55 530 3.2 1160 7200
AS 35_ 10.18 88 480 4.7 1160 6430 49 530 2.9 1160 7200
AS 35_ 11.43 79 480 4.2 1160 6790 44 530 2.6 1160 7200
AS 35_ 12.62 71 480 3.8 1160 6900 40 530 2.3 1160 7200
AS 35_ 15.37 59 480 3.1 1160 7200 33 530 1.9 1160 7200
AS 35_ 17.11 53 480 2.8 1160 7200 29.2 530 1.7 1160 7200
AS 35_ 19.21 47 480 2.5 1160 7200 26.0 530 1.5 1160 7200
AS 35_ 24.19 37 480 2.0 1160 7200 20.7 530 1.2 1160 7200
AS 35_ 29.45 31 480 1.6 1160 7200 17.0 530 0.99 1160 7200
AS 35_ 32.8 27.4 480 1.5 1160 7200 15.2 530 0.89 1160 7200
AS 35_ 36.82 24.4 480 1.3 1160 7200 13.6 530 0.79 1160 7200
AS 35 D_ 41.2 21.8 530 1.3 830 7200 12.1 530 0.73 830 7200
AS 35 D_ 46.2 19.5 530 1.2 830 7200 10.8 530 0.65 830 7200
AS 35 D_ 54.0 16.7 530 1.0 830 7200 9.3 530 0.55 830 7200
AS 35 D_ 65.8 13.7 530 0.82 830 7200 7.6 530 0.45 830 7200
AS 35 D_ 73.6 12.2 530 0.73 830 7200 6.8 530 0.41 830 7200
AS 35 D_ 82.2 10.9 530 0.66 830 7200 6.1 530 0.36 830 7200
AS 35 D_ 99.3 9.1 530 0.54 830 7200 5.0 530 0.30 830 7200
AS 35 D_ 120.9 7.4 530 0.45 830 7200 4.1 530 0.25 830 7200
AS 35 D_ 134.7 6.7 530 0.40 830 7200 3.7 530 0.22 830 7200
AS 35 D_ 151.1 6.0 530 0.36 830 7200 3.3 530 0.20 830 7200
