AS 30...HS
AS 30
A D E F F1 F2 F3 F4 V S SP
AS 30 P_HS
329 219 50 24 27.3 8 5 40 M8 6 19 23
AS 30 DP_HS
314 214 40 19 21.8 6 5 30 M6 5 16 22.5
AS 30 F_HS
329 219 50 24 27.3 8 5 40 M8 6 19 24
AS 30 DF_HS
314 214 40 19 21.8 6 5 30 M6 5 16 23.5
AS 30 R_HS
356 246 50 24 27.3 8 5 40 M8 6 19 22.5
AS 30 DR_HS
341 241 40 19 21.8 6 5 30 M6 5 16 23.5
P
DP
F
DF
R
DR
V
DIN 332 DR
SP
S
F2 h9
F1
F h6
M10
DIN 332 DR
22
7.5
8 h9
33
30 h6
OUTPUT
INPUT
