Bosch API-AMC2-16IOE User Manual

Extension board with 16-input 16-output Installation | en 11
Bosch Security Systems B.V.
Installation manual
2024-01 | V02 |
4.2 Unmounting the device from a mounting rail
i
Notice!
To remove the extension from a mounting rail, first remove all wired pluggable connectors.
Push down the extension until the lower edge snaps out of the mounting rail [1]. Pull the
lower end of the extension from the mounting rail [2].
1 2
Figure4.2: Unmounting the AMC2 device on a mounting rail
