16 en | Installation Extension board with 16-input 16-output

2024-01 | V02 |

Installation manual

Bosch Security Systems B.V.

4.6.1 Grounding for extension interface

A 1:

A 2:

Delivery status

Figure4.5: Location of ground jumper bottom side

A1 Delivery status

Jumper A connects the internal ground of the controller to the RS-485 ground of the slave

interface. Only set jumper A (A2) if the controller powers all other peripheral devices

directly connected to it.
