12 en | Installation Extension board with 16-input 16-output

2024-01 | V02 |

Installation manual

Bosch Security Systems B.V.

4.3 Opening the case

Notice!

To open the extension, first remove all wired pluggable connectors.

The extension’s case consists of a top cover mounted with a two-point snap-in closure on a

chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the

cover down.

Figure4.3: Opening the AMC2-16IOE case
