Extension board with 16-input 16-output UL requirements | en 27
Bosch Security Systems B.V.
Installation manual
2024-01 | V02 |
5 UL requirements
Before installing the product in an UL system, read and follow the UL requirements
described below.
Depending on the Host Management, the system consists of:
The Access Professional Edition (APE) 3.4 or 3.5 or Building Integration System (BIS) -
Access Engine (ACE) 4.5, or AMS 2.0 or 3.0 as the Host Management System. This is an
Access Control (UL 294 ALVY) system. It consists of the following devices - all listed to UL
294:
– The maximum number of controllers varies depending on the type of license (AMC2-
xWCF, downloader version 00.49 or higher, program version 37.xx).
– The AMC2-xWCF controller can be extended with one AMC2-4WE device.
– Every controller can be extended with up to three AMC2-8IOE, AMC2-16IOE or
AMC2-16IE in any combination.
– The enclosures AMC2-UL01 (for one device) or AMC2-UL02 (for two devices).
– For every enclosure, a power supply Bosch APS-PSU-60 is necessary, and must be
located in the same room as the connected AMC2 device. Recommended maximum
distance between power supply unit and AMC2 is 3 m (9.84 ft).
Notice!
The use of the burglar alarm, panic hardware, and elevator control have not been evaluated
by UL.
Notice!
This section applies to APC product versions. ADS product versions have not been
evaluated by UL.
5.1 System requirements
5.1.1 Computer
Host system
For detailed information about the needed Operating system and Hardware, please refer to
the corresponding installation manual of the used Management system.
Notice!
Computers used for UL installations must be UL listed by the Information Technology
Equipment Group (ITE).
5.2 UL 294 level descriptions
The following UL 294 levels apply:
– ACCESS CONTROL DESTRUCTIVE ATTACK LEVEL I - An access control product intended
for, but not limited to, a controlled area that is not required to meet the destructive
Attack Test.
– ACCESS CONTROL LINE SECURITY LEVEL I - An access control product with no
communication line security.
– ACCESS CONTROL ENDURANCE LEVEL IV - An access control product shall operate as
intended at rated voltage and current for 100,000 cycles of intended operation.
