Extension board with 16-input 16-output UL requirements | en 31
Bosch Security Systems B.V.
Installation manual
2024-01 | V02 |
Position Description Position Description
G Green or green / yellow 6 Tamper connection
1 AC power connection 7 Ethernet cable
2 DC power to AMC2 Grounding points
!
Caution!
Risk of electrical interference.
Make sure to keep the class 2 conductors and the non-power limited conductors strictly
separate.
- Avoid any crossing of the conductors of the two categories.
- Guide the conductors of the two categories through different knock-outs of the housing.
5.4 Extended technical specification
5.4.1 RS-485 extension
– RS-485 extension output power rated maximum 2.5 A @ 9.0 VDC to 30 VDC
(the voltage output is dependent on board voltage input)
5.4.2 Power consumption
Power input 10 VDC to 30 VDC, maximum of 3 A
Power consumption 5 VA
Total combined output 3 A @ 10 VDC - 12 VDC
2.5 A @ 24 VDC - 30 VDC
