30 en | UL requirements Extension board with 16-input 16-output
2024-01 | V02 |
Installation manual
Bosch Security Systems B.V.
Figure5.1: Example of mountings with extensions
Position Description Position Description
B Black / brown 3 Battery connection
4 Earth cable
W Blue 5a
5b
R-485 extension connection
