Bosch API-AMC2-16IOE User Manual

Extension board with 16-input 16-output Installation | en 23
Bosch Security Systems B.V.
Installation manual
2024-01 | V02 |
C
NO/NC
1
2
3
4
Figure4.14: Recovery diode schematic
1 Normally open / normally closed 2 Common
3 Inductive load 4 Recovery diode
i
Notice!
When you use the recovery diode, make sure to use it in the reverse direction.
E 1:
E 2:
14 131516
9
10
11
12
14 131516
5
6
78
56
78
12 11
10
9
4 3 2
1
4 3 2
1
Figure4.15: Location of relay output jumpers (bottom side)
E1 Delivery status
