18 en | AVENAR panel series AVENAR panel
2022-07 | 5.0 | F.01U.378.910
System manual
Bosch Sicherheitssysteme GmbH
– FBH0000A Mounting Frame Large
– FMH0000A Mounting Frame Medium
– FSH0000A Mounting Frame Small
The housings for frame installation require the following mounting frames for surface-mounted
version:
Housing type Mounting frames
CPH 0006 A FBH0000A
MPH 0010 A FBH0000A
EPH 0012 A FBH0000A
PSF 0002 A FSH 0000 A
PMF 0004 A FMH 0000 A
USF 0000 A FSH 0000 A
Notes:
– All mounting frames have an opening for routing cables that is sealed with an insert. Pre-
punched cable entries can be created from this insert.
– The FBH0000A and FHS0000A mounting frames are equipped with an earth bar ex
works.
– For the FMH0000A, the FPO‑5000‑EB Earth Bar can be ordered as an extension if
required.
– For continuous installation in combination, all mounting frames have T-shaped guide rails
on the base and T-shaped grooves on the top.
Mounting Plate
An HMP0003A Mounting plate can be mounted in large mounting frames FBH0000A and
FHS 0000 A; this mounting plate can be individually equipped. It contains fixing holes for a
distributor rail.
USF 0000 A is fitted with a mounting plate ex works, which can be equipped as required. It
contains fixing holes for two distributor rails.
Equipment Limits
The table below shows the maximum number of:
– Modules
– Panel rails (short PRS-0002-C, long PRD 0004 A)
Housing type Modules Short rails Long rails
CPH 0006 A 6 1 1
MPH 0010 A 10 1 2
EPH 0012 A 12 - 3
PSF 0002 A - - -
PMF 0004 A - - -
USF 0000 A - - -
The table below shows the maximum number of:
– Panel controllers
– UPS power supply units
– Batteries
