Housing type Panel controller UPS power
supply units
Batteries
CPH 0006 A 1 1 2x45Ah
MPH 0010 A 1 - -
EPH 0012 A - - -
PSF 0002 A - 1 2x45Ah
PMF 0004 A - 1 4x45Ah
USF 0000 A - - -
Installation Kits for 48cm (19") racks
Special installation kits are available for installing the frame installation housing in 482.6mm
(19") racks:
Housing type Installation kit, 482.6mm
CPH 0006 A FRB 0019 A
MPH 0010 A FRB 0019 A
EPH 0012 A FRB 0019 A
PSF 0002 A FRB 0019 A
PMF 0004 A FRM 0019 A
USF 0000 A FRS 0019 A
No mounting frame is required when using the 482.6mm installation kits.
Scope of Delivery
Housing type Scope of delivery (each x 1)
CPH 0006 A - Housing, painted sheet steel
- Power supply bracket
- Sheet steel front panel with plastic cover
- Accessories pack with installation material
MPH 0010 A - Housing, painted sheet steel
EPH 0012 A - Housing, painted sheet steel
PSF 0002 A - Housing, painted sheet steel
- Power supply bracket
- Cable set for battery connection
PMF 0004 A - Housing, painted sheet steel
- Power supply bracket
- Cable set for battery connection
USF 0000 A - Housing, painted sheet steel
- Mounting plate
