7.29 Register (0x32) Out-of-range (OOR) threshold for pressure (LSB)
Bit
7
6
5
4
3
2
1
0
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
oor_thr_p_7_0
 oor_thr_p_7_0:(bit offset: 0) OOR pressure threshold, bits 7:0
7.30 Register (0x33) Out-of-range (OOR) threshold for pressure (MSB)
Bit
7
6
5
4
3
2
1
0
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
oor_thr_p_15_8
 oor_thr_p_15_8:(bit offset: 0) OOR pressure threshold, bits 15:8
7.31 Register (0x34) Out-of-range (OOR) range configuration
Bit
7
6
5
4
3
2
1
0
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
oor_range_p
 oor_range_p:(bit offset: 0) OOR pressure range
7.32 Register (0x35) Out-of-range (OOR) configuration
Bit
7
6
5
4
3
2
1
0
Read/Write
R/W
R/W
R
R
R
R
R
R/W
Reset Value
0
0
0
0
0
0
0
0
Content
cnt_lim
reserved_5_1
oor_thr...
 oor_thr_p_16:(bit offset: 0) OOR pressure threshold, bit 16
 reserved_5_1:(bit offset: 1) reserved
 cnt_lim:(bit offset: 6) OOR count limit (Note: This field cannot be written during an ongoing P/T conversion.)
Value Description
0b000 (0x0)
Counter limit of 1
0b11 (0x3)
Counter limit of 3
0b111 (0x7)
Counter limit of 7
0b1111 (0xF)
Counter limit of 15
