Addressing Output modules are hardware−addressed.
Possible start addresses for the individual 8−channel, 16−channel and
32−channel O modules are listed in the following table. An addressing
example is explained in paragraph 4.3.1.
n−channel
Ocard

PermissibleStartAddresses
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
32 33 34 35 36 37 39 40 41 42 43 44 45 46 47
48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
0 2 4 6 81012141618202224262830
32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62
0 4 812162024283236404448525660
8
16
32
38
Fig.4−22Addressing
.Note,
The output modules require the 0 V connection and an additional external power supply.
Ordering Information Output Module Order No.
24VDC 0.2 A 32outputs 047964
24VDC 0.5A 32outputs short−circuit proof 050560
24VDC 0.5A 16outputs 048483
24VDC 2A 16outputs 048485
24VDC 2A 16outputs short−circuit proof 050634
24VDC 2A 16outputs2−pin 044305
24VDC 2A 8outputs 041438
230/115VAC 2A 8outputselectronic 048862
220VAC relay 16 outputs2−pin 044834
