SoftwareDescription
FlexibleAutomation
5−21
5.4.3 Addressing Modes
Register Register Example
LWA,B
The content of register A is loaded into register B.
ACCUA
RegisterB
RegisterC
Fig.5−18Register Register
Register Direct Example
L BY E15,B
The content of a peripheral address is loaded into a register.
ACCUA
RegisterB
RegisterC
I
15.7............... 15.0
Fig.5−19Register Direct
Register Immediate Example
L W K1234H,B
A constant indicated in the command is loaded into a register.
