Configuration
FlexibleAutomation
2−28
2.2 Electrical Configuration
2.2.1 Regulations
The electrical connections of the CL300 Controller should comply with the regula
tions VDE 0100 and VDE 0113.
2.2.2 External Power Supply
Power for actuators and transducers is not supplied by the NT300/301 Power Sup
ply Unit. Therefore, a separate load power supply is required.


380V+5%
380V
380V−5%
L1 L2 L3
PE
+24V0V
F
Fig.2−16Wiring Diagram
