SystemModules
FlexibleAutomation
4−3
List of Illustrations
Fig. Page
4−1 Power Supply Units NT300/301 4−8. . . . . . . . . . . . . . . . . .
4−2 Settings NT300/301 4−9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−3 Buffer Battery NT300 4−11. . . . . . . . . . . . . . . . . . . . . . . . . . .
4−4 Buffer Battery NT301 4−12. . . . . . . . . . . . . . . . . . . . . . . . . . .
4−5 ZE300/301 4−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−6 ZE300/301 Settings 4−20. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−7 Central Processing Units ZE300/301 4−22. . . . . . . . . . . . .
4−8 Specifications of input modules 4−28. . . . . . . . . . . . . . . . . .
4−9 Start Addresses 4−29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−10 Addressing Example, DIL switches 4−29. . . . . . . . . . . . . . .
4−11 Addressing Example 4−30. . . . . . . . . . . . . . . . . . . . . . . . . . .
4−12 E 24V DC 32inputs 4−31. . . . . . . . . . . . . . . . . . . . . . . . . . .
4−13 E 24V DC 16inputs 4−32. . . . . . . . . . . . . . . . . . . . . . . . . . .
4−14 E 24V DC 16inputs 2−pin 4−33. . . . . . . . . . . . . . . . . . . . .
4−15 E 220V AC 16inputs 2−pin 4−34. . . . . . . . . . . . . . . . . . . .
4−16 Maximum configuration (220V units) 4−35. . . . . . . . . . . . .
4−17 E 115V AC 16inputs 2−pin 4−36. . . . . . . . . . . . . . . . . . . .
4−18 Maximum configuration (115V units) 4−37. . . . . . . . . . . . .
4−19 Input address range IE 24− 16inputs 4−39. . . . . . . . . . . .
4−20 High−speed Interruptable Input Module IE 24− 4−40. . .
4−21 Specifications of output modules 4−45. . . . . . . . . . . . . . . .
4−22 Addressing 4−48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−23 A 24V DC 0.2A 32outputs 4−49. . . . . . . . . . . . . . . . . . . . .
4−24 A 24V DC 0.5A−e 32outputs
short−circuit proof 4−50. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4−25 Simultaneity 4−51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
