Bosch CL300 - Central Processing Units ZE300;301

SystemModules
FlexibleAutomation
4−22
4.2.4 Front Panel
MountingScrew
RedLED"I/Oforced"
"FixReset"button
RedLED"ZEinStop"
RUN/STOPSwitch
"Inhibitoutputs"Switch
"Remanency"Switch
StatusDisplay
MemoryModuleSlot
25−pinDconnector
MountingScrew

ZE300

RAM 300
Status
Fix
Reset



Stop
Run
Ausg.
sperren
Rem.
PG
Fig.4−7Central Processing Units ZE300/301
