SystemModules
FlexibleAutomation
4−21
Setting of the Baud Rate The baud rate is set to the values in the table below, using the 8−seg
ment DIP switch S1 (see Fig.4−6).
Transfer Rate DIP Switch Positions
(Baud) Switch 1 Switch 2 Switch 3
110 OFF OFF OFF
300 ON OFF OFF
600 OFF ON OFF
1200 ON ON OFF
2400 OFF OFF ON
4800 ON OFF ON
9600 OFF ON ON
19200 ON ON ON
Basic settings The ZE is supplied with the following basic settings:
D 9600 baud transfer rate
D Asynchronous
D 1 start bit
D 8 data bits
D Even parity
D 1 stop bit
D JP2 in position B" (with control signals)
