Parallel expansion may include one basic station (1 GG Basic Unit con
nected in series with 2 expansion units) and up to 3 expansion stations (3
expansion units each).
Connection The AG/P Expansion Module is connected to the expansion station with
0.55 m or 1.8 m standard interconnection cables.
Slots With purely parallel expansion the AG/P cards can occupy the last 3 slots
in the basic unit.
With distributed expansion the AG/P can be installed in the expansion
unit in slots 1, 2, 13 or 14. For further information see paragraph 2.1.12.5.
Power Supply The internal voltages for the expansion stations are provided by the
power supply unit installed in the basic unit. Power consumption of the
individual modules and units is indicated in paragraph 2.2.4.
Protective Ground Connection All expansion stations must be connected to the central protective
ground terminal (see paragraph 2.2.3).
Specifications Cable Length Between AG/P and AG/Z 0.55m or 1.8m
Power Consumption 12V 85mA
Width 1 module width
Dimensions Dual Eurocard format
.Note,
A detailed description of the AG/P Module is given in Module Description" P.−No. 3791.
Ordering Information Order No.
AG/P Parallel Expansion Module 047944
Interconnection Cable 1.8 m 048081
Interconnection Cable 0.55 m 041535
