SystemModules
FlexibleAutomation
4−23
Red LED "I/O forced LED lights when a signal of any kind is forced.
"Fix Reset" Fix Reset" button to delete all active forcings
Red LED ZE in STOP" When the LED lights, program execution is stopped and all outputs are
reset to zero.
RUN/STOP Switch D In RUN mode the program is executed.
D In STOP mode the program is interrupted.
Inhibit outputs" Switch Outputs are reset to zero.
Remanency" Switch When remanency is activated, the remanent markers,timers and count
ers are buffered by the buffer battery in case of power failure.
25−pin D connector 25−pin D connector to accommodatethe combined V.24/20 mA inter
face for the connection of a programming unit.
