Configuration
FlexibleAutomation
2−29
Specifications Input Voltage 380 V/3−phase/50 Hz
Output Voltage 24 V DC to DIN 19240
Peak−to−average Ripple Factor 5 %
Max. Output Current 6A, 10A, 20A, 40A
Input Current at Nominal Load 0.3A, 0.45A, 0.83A, 1.7A
Connecting Terminals (mm@) 1.5, 1.5, 2.5, 2,5
Protection Class IP00
Dimensions H x W x D 165 mm x 300 mm x 100 mm,
185 mm x 340 mm x 140 mm,
240 mm x 420 mm x 140 mm
Ordering Information Order No.
24VDC 6A 913485
10A 913486
20A 913487
40A 913488
2.2.3 Protective Ground Connection
With the use of expansion modules, the following points should be observed to en
sure good protective ground connection:
D The basic unit and all expansion units should be connected to the protective
ground wire. The connecting cross−section should be as large as possible.
D The flat−cable connector on the front panel of the destination expansion unit
should be connected to the protective ground wire when two AG/Z units are
interconnected.
D When an AG/P module is connected to an AG/Z module, the flat−cable con
nector on the AG/Z front panel should be connected to the protective ground
wire.
D In case of interference problems, it is recommended to also connect the flat−
cable connector on the AG/P front panel to the protective ground wire.
