4.4.2 Analog Output Module with 4 Output Channels
Function The analog output module is used to output analog voltages and cur
rents.
Since the output module is used in the extended outputs, it has no effect
on the number of digital modules. It occupies one word in the extended
output range (EO).
.Note,
Analog output modules must not have the same addresses as analog input modules.
The module contains 4 output channels which may independently as
sume any voltage or current value, according to the range being set. All
voltages or currents are referenced to a common ground potential.
The outputs are electrically isolated through optocouplers.
A detailed description of the analog output module is given in Technical
Description", P. − N o . 3778.
Specifications Voltage Ranges 10V, 5V, 2.5V
Current Ranges 20mA, 10 mA, 5mA
Number of Outputs 4
Max. Number of Cards per CL300 32
Wiring Twisted pair, shielded
Max. Cable Length 200m
Max. Burden Resistance U:  500W, I:  500W
referenced to 0 V
Short−circuit Protection Permanent short−
circuit
protection
Grade 0.2% typical
0.5% max.
