Connection The connection is made through a 0.55 m cable and the two 50−pin fe
male connectors on the module front panel. These two connectors are
connected in parallel so that the connection can optionally be made us
ing the upper or the lower connector.
Slot The AG/Z is to be installed in slot 14 of the GG300/301 and in slot 8 of the
GG300−K/301−K basic unit. It can be installed in slots 1, 2, 13 or 14 in
expansion units, depending on the configuration. For further information
see paragraph 2.1.12.5.
Specifications Width 1 module width
Cable length between 2 Expansion Modules 0.55 m
Internal Power Consumption 12 V/10 mA
Ordering Information Order No.
AG/Z Central Expansion Module 041523
Interconnection Cable 0.55 m 041535
