SoftwareDescription
FlexibleAutomation
5−24
SM28.0−28.7 Error Byte
SM28.0 Module Stack Error
SM28.1 Opcode Error
SM28.2 Addressing Error
SM28.3 Module Management Error
SM28.4 Controller Addressing Error
SM28.5 Parameter Error
SM28.6 C/T Set−point Error
SM28.7 Cycle Time Error
System Range Code List S0 (Bit 1) I/O allocation list desired
S0 (Bit 2) Copy data module to data buffer
S2 Main software watchdog (factor * 10 ms)
S4 Time base definition for time−controlled processing in
OM5
S6 Time base definition for time−controlled processing in
OM6
S8 Defining length and number of module to be coied
S10 Defining the limiting (byte) address for marker
remanency
S12 Defining the limiting (byte) address for timer
remanency
S14 Defining the limiting (byte) address for counter
remanency
S16−S46 Set allocation lists for input and output modules
S16−S22 4 words for input allocation
S24−S30 4 words for output allocation
S32−S38 4 words for extended input allocation
S40−S46 4 words for extended output allocation
Representation of Constants K0000000000000000B−K1111111111111111B Binary value
K000000O−K177777O Octal value
K00000D−K65535D Decimal value
K0000H−KFFFFH Hexadecimal
value
K"AB" 2 ASCII char
acters
K0C−K8191C Counter value
K0.TB−K999.TB
Timer value
Time values are not entered directly, but with a time base indication.
TB = 010 ms
TB = 1 100 ms
TB = 21s
TB = 3 10s
