Configuration
FlexibleAutomation
2−15
EG300ExpansionUnit
EG300ExpansionUnit
ZENT300/
301
GG300/301BasicUnit
Ifnecessary,provideclearance
100mm
100mm
100mm
100mm
Ifnecessary,provideclearance
Shelf1
Shelf2
Shelf3
Ifnecessary,provideclearance
Ifnecessary,provideclearance
Fig.2−8Example of a Multi−shelf Configuration
