DS7200V2-UK Installer's Guide Copyright 2007 Bosch Security Systems, Inc. P/N: 4998152533-02 Page 99
PART IV: CONTROL PANEL PROGRAMMING
48.0 RS-232 Module Configuration
The following parameters apply to the DX4010i and DX4010 RS-232 Serial Interface Modules.
Output Configuration Options
• Address: 1253
• Default: 0 (Disabled)
• Selections:
−
0 = Disabled(no RS-232 module connected)
− 1 = RS-232 Log Output using Internal Codes
− 2 = RS-232 Log Output using PC Compatible Codes
Set the module to Data Bus Address 250. See DX4010i/DX4010 Addressing on page 27 for information.
This parameter only applies when the module is used for RS-232 serial output. It does not apply if the module is used for
direct-connect local programming.
• RS-232 Log Output using Internal Codes: If enabled, this option outputs the events using the internal keypad character
codes. Non-standard characters may not print correctly.
• RS-232 Log Output using PC Compatible Codes: If enabled, this option outputs the events using PC compatible
character codes. Non-standard characters are mapped to the closest matching character for display or printing.
If you connect a printer to the module and get unexpected results, check the module output
configuration (Address 1253), baud rate configuration (Address 1254) and parity/flow control/stop bit
configuration (Address 1255) for proper settings.
Baud Rate Options
• Address: 1254
• Default: 2 (2400 bps)
• Selections:
−
1 = 1200 bps
− 2 = 2400 bps
− 3 = 4800 bps
− 4 = 9600 bps
− 5 = 14400 bps
This parameter identifies which baud rate the module should use for communication.
If you connect a printer to the module and get unexpected results, check the module output
configuration (Address 1253), baud rate configuration (Address 1254) and parity/flow control/stop bit
configuration (Address 1255) for proper settings.
