DS7200V2-UK Installer's Guide Copyright 2007 Bosch Security Systems, Inc. P/N: 4998152533-02 Page 11
PART II: SYSTEM INSTALLATION AND SETUP
Part II: System Installation and Setup
10.0 Control Panel Installation
The control panel and the CX1011 enclosure are
shipped together. Hardware to mount the enclosure is
not supplied.
Only qualified, authorized service personnel
should install and maintain this system.
Bosch Security Systems recommends
testing the entire system at least once a
week and having a qualified technician
check the system at a minimum of once
every three years.
As this is permanently connected
equipment, a readily accessible disconnect
device shall be incorporated into the
building installation wiring.
The PCB contains static-sensitive
components and must be handled with care.
Follow anti-static procedures when handling
it.
Touch the control panel’s earth ground
terminal to discharge any static charge you
may be carrying before working on the
control panel.
10.1 Electro Magnetic Interference (EMI)
EMI might occur if you install the system or
run system wires near any of the following:
• Computer network system
• Electrical lines, fluorescent fixtures or telephone
lines
• Amateur radio transmitter site
• Heavy machinery and motors
• High voltage electrical equipment or transformers
• PBX telephone system
• Public service (police, fire, etc.) using radio
communications
• Radio station transmitter site or other broadcast
station equipment
• Welding shop
If you think that EMI might be a problem, use shielded
cable. The drain wire for the shielded cable must have
continuity from the earth ground terminal on the
control panel to the end of the wire run. If continuity is
not maintained, the shielded cable might aggravate
potential noise problems rather than eliminate them.
Connecting the drain wire to ground at any place
other than the earth ground terminal might also create
problems. If you cut the drain wire to install devices,
be certain to splice it together. Carefully solder and
tape all splices.
