PART IV: CONTROL PANEL PROGRAMMING
38.0 Users
This section details configuring each user’s PIN, authority level and area assignment. The DS7240V2-UK supports up to 32
users.
The panel reserves the following User IDs for automated functions: 251 (control panel generated); 252 (Sked operation); 253
(remote telephone communication); 254 (RPS communication); 255 (keyswitch operation or any local operation that does not
require a PIN entry, such as Quick Arming).
See
Table 26 for User parameter addresses and defaults (defaults are shown like this).
Personal Identification Number (PIN) Addresses Authority
Level
Area
User # Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Selection Selection
1
Addr 0390
(1)
Addr 0391
(2)
Addr 0392
(3)
Addr 0393
(4)
Addr 0394
(0)
Addr 0395
(0)
Addr 0396
(0)
Addr 0397
(1)
Addr 0398
(15)
2
Addr 0399
(15)
Addr 0400
(15)
Addr 0401
(15)
Addr 0402
(15)
Addr 0403
(15)
Addr 0404
(15)
Addr 0405
(15)
Addr 0406
(2)
Addr 0407
(1)
3
Addr 0408
(15)
Addr 0409
(15)
Addr 0410
(15)
Addr 0411
(15)
Addr 0412
(15)
Addr 0413
(15)
Addr 0414
(15)
Addr 0415
(3)
Addr 0416
(1)
4
Addr 0417 Addr 0418 Addr 0419 Addr 0420 Addr 0421 Addr 0422 Addr 0423 Addr 0424 Addr 0425
5
Addr 0426 Addr 0427 Addr 0428 Addr 0429 Addr 0430 Addr 0431 Addr 0432 Addr 0433 Addr 0434
6
Addr 0435 Addr 0436 Addr 0437 Addr 0438 Addr 0439 Addr 0440 Addr 0441 Addr 0442 Addr 0443
7
Addr 0444 Addr 0445 Addr 0446 Addr 0447 Addr 0448 Addr 0449 Addr 0450 Addr 0451 Addr 0452
8
Addr 0453 Addr 0454 Addr 0455 Addr 0456 Addr 0457 Addr 0458 Addr 0459 Addr 0460 Addr 0461
9
Addr 0462 Addr 0463 Addr 0464 Addr 0465 Addr 0466 Addr 0467 Addr 0468 Addr 0469 Addr 0470
10
Addr 0471 Addr 0472 Addr 0473 Addr 0474 Addr 0475 Addr 0476 Addr 0477 Addr 0478 Addr 0479
11
Addr 0480 Addr 0481 Addr 0482 Addr 0483 Addr 0484 Addr 0485 Addr 0486 Addr 0487 Addr 0488
12
Addr 0489 Addr 0490 Addr 0491 Addr 0492 Addr 0493 Addr 0494 Addr 0495 Addr 0496 Addr 0497
13
Addr 0498 Addr 0499 Addr 0500 Addr 0501 Addr 0502 Addr 0503 Addr 0504 Addr 0505 Addr 0506
14
Addr 0507 Addr 0508 Addr 0509 Addr 0510 Addr 0511 Addr 0512 Addr 0513 Addr 0514 Addr 0515
15
Addr 0516 Addr 0517 Addr 0518 Addr 0519 Addr 0520 Addr 0521 Addr 0522 Addr 0523 Addr 0524
16
Addr 0525 Addr 0526 Addr 0527 Addr 0528 Addr 0529 Addr 0530 Addr 0531 Addr 0532 Addr 0533
17
Addr 0534 Addr 0535 Addr 0536 Addr 0537 Addr 0538 Addr 0539 Addr 0540 Addr 0541 Addr 0542
18
Addr 0543 Addr 0544 Addr 0545 Addr 0546 Addr 0547 Addr 0548 Addr 0549 Addr 0550 Addr 0551
19
Addr 0552 Addr 0553 Addr 0554 Addr 0555 Addr 0556 Addr 0557 Addr 0558 Addr 0559 Addr 0560
20
Addr 0561 Addr 0562 Addr 0563 Addr 0564 Addr 0565 Addr 0566 Addr 0567 Addr 0568 Addr 0569
21
Addr 0570 Addr 0571 Addr 0572 Addr 0573 Addr 0574 Addr 0575 Addr 0576 Addr 0577 Addr 0578
22
Addr 0579 Addr 0580 Addr 0581 Addr 0582 Addr 0583 Addr 0584 Addr 0585 Addr 0586 Addr 0587
23
Addr 0588 Addr 0589 Addr 0590 Addr 0591 Addr 0592 Addr 0593 Addr 0594 Addr 0595 Addr 0596
24
Addr 0597 Addr 0598 Addr 0599 Addr 0600 Addr 0601 Addr 0602 Addr 0603 Addr 0604 Addr 0605
25
Addr 0606 Addr 0607 Addr 0608 Addr 0609 Addr 0610 Addr 0611 Addr 0612 Addr 0613 Addr 0614
26
Addr 0615 Addr 0616 Addr 0617 Addr 0618 Addr 0619 Addr 0620 Addr 0621 Addr 0622 Addr 0623
27
Addr 0624 Addr 0625 Addr 0626 Addr 0627 Addr 0628 Addr 0629 Addr 0630 Addr 0631 Addr 0632
28
Addr 0633 Addr 0634 Addr 0635 Addr 0636 Addr 0637 Addr 0638 Addr 0639 Addr 0640 Addr 0641
29
Addr 0642 Addr 0643 Addr 0644 Addr 0645 Addr 0646 Addr 0647 Addr 0648 Addr 0641 Addr 0642
30
Addr 0651 Addr 0652 Addr 0653 Addr 0654 Addr 0655 Addr 0656 Addr 0657 Addr 0658 Addr 0659
31
Addr 0660 Addr 0661 Addr 0662 Addr 0663 Addr 0664 Addr 0665 Addr 0666 Addr 0667 Addr 0668
32
Addr 0669 Addr 0670 Addr 0671 Addr 0672 Addr 0673 Addr 0674 Addr 0675 Addr 0676 Addr 0677
Table 26: User Configuration
User 28 is the Guard Code User. See Guard Code Options on page 71 for more information.
User 32 is the default Duress User. See Duress Reporting Options on page 70 for more information.
