Fig. 1 Model Nomenclature
1 2 34567 8 910111213141516171819202122232425262728293031323334353637383940
SM024-1VTC - F L TADC - XMGXXXXXD7XXX
X
5XXXXSBA
SM
PREMIUM SERIES
SIZE
024, 036,
048, 060, 070
VOLTAGE
1 208-230/60/1
CABINET CONFIGURATION
HZ- HORIZONTAL
VT- VERTICAL
COAX OPTIONS
C- COPPER
N- CUPRO-NICKEL
WATER CONNECTIONS
F- FRONT
RETURN AIR CONFIGURATION
L- LEFT
R- RIGHT
DISCHARGE AIR CONFIGURATION
T- TOP (VT ONLY)
E- END (HZ ONLY)
FAN/MOTOR OPTIONS
A- CONSTANT AIRFLOW ECM
AIR COIL
D- DUOGUARD/SS DRAIN PAN (VT ONLY)
T- TIN PLATED (HZ ONLY)
REVISION LEVEL
B- ( VT ONLY)
A- (HZ ONLY)
CODE STRING LEVEL
CHANNEL
B- BOSCH
STANDARD/SPECIAL
S- STANDARD
AGENCY OPTIONS
X- ETL (UL 1995)
OPEN
DRIVE SPEED
X- N/A
ELECTRIC HEAT
X- NONE
CABINET CONSTRUCTION
M- PAINTED STEEL/ ½” CLOSED CELL FOAM, EXTRA QUIET (TO INCLUDE
COMPRESSOR BLANKET AS STANDARD) (VT & CF ONLY)
H- PAINTED STEEL/ ½” CLOSED CELL FOAM (HZ ONLY)
APPLICATION
G- EXTENDED RANGE
GENERAL ELECTRICAL OPTIONS (UP TO 5 AVAILABLE PER UNIT)
X- AS DEFAULT FOR NON USED ELECTRICAL CODES
REFRIGERATION CIRCUIT OPTIONS
D- HEAT RECOVERY PACKAGE
MOTOR HP/QTY
X- N/A
AIR FILTRATION
4- MERV8 - 2" w/ 4-SIDED FILTER RACK (REV B&C, VT cŽŶĮguraƟon)
5- MERV13 - 2" w/4-SIDED FILTER RACK (REV A&C, HZ cŽŶĮguraƟon)
ECONOMIZER
X- NONE
WATER FLOW CONTROL OPTIONS
X- NONE
OPEN
CONTROLS
H- HEAT PUMP CONTROL
TRANSFORMER
7-75 VA
C- ( VT & HZ)
