Water Side Pressure Drop Table for HZ Units
Table 15 Water Side Pressure Drop Table for HZ Units
MODEL
GPM
Heat Pump Water Pressure Drop
Additional Pressure Drop in
Hose Kit*
Water PD @ 77°EWT with Water
in PSI
Water PD in PSI
SM024
3 0.7 0.04
4 1.2 0.04
5
1.7 0.09
6 2.4 0.09
7
3.2 0.13
8 4.0 0.17
SM036
4.5 1.3 0.09
6 2.2 0.09
7.5
3.2 0.17
9 4.5 0.22
10.5
5.9 0.30
12 7.5 0.35
SM048
6 1.1 0.09
8 1.8 0.17
10
2.7 0.26
12 3.7 0.35
14
4.9 0.48
16 6.2 0.61
SM060
7.5 1.1 0.17
10 1.9 0.26
12.5
2.8 0.39
15 3.9 0.52
17.5
5.2 0.69
20 6.6 0.91
SM070
9 2.4 0.22
12 4.0 0.36
15
6.0 0.53
18 8.3 0.72
21 3.9 0.95
24 5.0 1.21
* Hose kit pressure drop based on straight hose. Pressure drop may vary depending on installation of hose kits.
