33
Operation
NOTICE
Attempting to remove the control computer when the
removal lock is engaged will damage the holder
Risk of damage!
• Check whether the blocking screw is inserted before
removing the control computer�
Fig.: Inserting the control computer
1 Locking mechanism 2 Holder
1
2
12.2.3 Removal lock
The control computer can be locked in the holder to prevent re-
moval�
• If you have no experience mounting bicycle components, have
your specialist dealer mount the removal lock�
1� Disconnect the holder from the handlebars�
2� Place the control computer in the holder�
3� Screw the blocking screw (M3 × 8 mm) into the threading of
the holder from below (see Fig�: “Control computer holder”)�
4� Mount the holder back on the handlebars�
Fig.: Control computer holder
1 Blocking screw
1
12.2.4 Power supply
When the e-bike is switched on and the rechargeable battery is
charged, the inserted control computer is supplied with energy via
the e-bike rechargeable battery�
The control computer that has been removed is supplied with power
from an internal rechargeable battery�
If the internal rechargeable battery is weak when you activate the
control computer, “Attach to bike” will appear for 3 seconds in the
text display field (see Fig.: “Control computer”)� The control com-
puter will switch back off afterwards�
