Service Manual Bosch IDS 2.0 | 15
Bosch Thermotechnology Corp. | 07.2021
Data subject to change
BOVA 36 + BVA 24 For Cooling
Indoor
Airfl ow (CFM)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
860
(High Stage)
15
TC 22.2 22.5 23.0 23.2 23.0 23.2 23.5 23.7 24.5 24.7 25.0 23.3 / 31.6 31.9 32.2
S/T 0.96 1.00 0.99 1.00 0.66 0.90 0.97 1.00 0.39 0.58 0.77 1.00 / 0.38 0.53 0.68
kW 0.66 0.67 0.68 0.68 0.68 0.69 0.69 0.70 0.69 0.70 0.72 0.62 / 1.14 1.16 1.18
65
TC 22.3 22.5 23.0 23.3 23.0 23.3 23.5 23.8 24.6 24.8 25.0 25.3 / 31.1 31.4 31.7
S/T 0.96 1.00 1.00 1.00 0.66 0.90 0.97 1.00 0.39 0.58 0.77 0.95 / 0.39 0.54 0.68
kW 0.99 1.00 1.01 1.01 1.01 1.02 1.04 1.05 1.04 1.06 1.07 1.08 / 1.41 1.43 1.45
75
TC 22.0 22.3 22.8 23.0 22.8 23.0 23.3 23.5 24.4 24.7 24.8 24.8 / 31.2 31.4 31.7
S/T 0.96 1.00 1.00 1.00 0.66 0.90 0.97 1.00 0.39 0.58 0.77 1.00 / 0.39 0.54 0.68
kW 1.23 1.25 1.26 1.26 1.26 1.27 1.29 1.30 1.31 1.32 1.33 1.33 / 1.66 1.68 1.70
85
TC 21.9 22.1 22.6 22.9 22.6 22.9 23.1 23.4 24.4 24.5 24.6 24.8 / 30.8 31.1 31.3
S/T 0.96 1.00 1.00 1.00 0.66 0.90 0.97 1.00 0.39 0.59 0.78 1.00 / 0.39 0.54 0.69
kW 1.36 1.38 1.39 1.39 1.39 1.41 1.42 1.44 1.46 1.46 1.46 1.48 / 1.81 1.83 1.85
95
TC 21.7 22.0 22.5 22.7 22.5 22.7 22.9 23.2 24.0 24.2 24.4 24.6 / 30.5 30.7 30.9
S/T 0.96 1.00 0.99 1.00 0.66 0.90 0.97 1.00 0.39 0.59 0.78 1.00 / 0.39 0.54 0.69
kW 1.62 1.64 1.66 1.66 1.66 1.68 1.69 1.71 1.73 1.74 1.75 1.77 / 2.19 2.21 2.22
105
TC 21.5 21.8 22.3 22.5 22.3 22.5 22.8 23.0 23.8 24.0 24.2 24.5 / 30.0 30.2 30.5
S/T 0.95 1.00 1.00 1.00 0.66 0.90 0.97 1.00 0.39 0.59 0.78 1.00 / 0.39 0.54 0.70
kW 1.95 1.97 1.99 1.99 1.99 2.01 2.03 2.05 2.06 2.08 2.09 2.11 / 2.63 2.65 2.68
115
TC 21.4 21.6 22.1 22.3 22.1 22.3 22.6 22.8 23.6 23.8 24.0 24.2 / 28.8 28.8 28.7
S/T 0.95 1.00 1.00 1.00 0.66 0.90 0.97 1.00 0.39 0.59 0.79 0.99 / 0.39 0.55 0.72
kW 2.31 2.33 2.36 2.36 2.36 2.38 2.41 2.43 2.44 2.46 2.48 2.50 / 3.00 3.00 3.00
125
TC 16.8 17.0 17.4 17.6 17.4 17.6 17.7 17.9 18.8 18.9 18.9 18.9 / 20.1 20.1 20.1
S/T 1.00 1.00 1.00 1.00 0.66 0.92 1.00 1.00 0.40 0.65 0.90 1.00 / 0.40 0.64 0.87
kW 1.97 1.99 2.01 2.01 2.01 2.03 2.05 2.07 2.11 2.11 2.11 2.11 / 2.12 2.12 2.12
1080
15
TC 25.8 26.1 26.7 27.0 26.7 27.0 27.3 27.6 28.6 28.8 29.1 29.4 / 36.1 36.4 36.6
S/T 0.98 1.00 1.00 1.00 0.67 0.90 0.97 1.00 0.39 0.60 0.80 0.99 / 0.38 0.55 0.71
kW 1.04 1.05 1.06 1.06 1.06 1.07 1.08 1.09 1.09 1.10 1.12 1.13 / 1.59 1.62 1.64
65
TC 25.9 26.2 26.8 27.1 26.8 27.1 27.4 27.7 28.6 28.8 29.1 29.4 / 36.1 36.4 36.6
S/T 0.98 1.00 1.00 1.00 0.67 0.90 0.97 1.00 0.39 0.60 0.80 0.99 / 0.38 0.55 0.71
kW 1.33 1.34 1.36 1.36 1.36 1.37 1.39 1.40 1.40 1.41 1.43 1.44 / 1.90 1.93 1.95
75
TC 26.0 26.3 26.9 27.2 26.9 27.2 27.5 27.8 28.7 29.0 29.2 29.5 / 36.1 36.4 36.7
S/T 0.97 1.00 1.00 0.99 0.67 0.90 0.97 1.00 0.39 0.59 0.80 1.00 / 0.38 0.55 0.71
kW 1.56 1.57 1.59 1.59 1.59 1.61 1.62 1.64 1.64 1.66 1.68 1.69 / 2.07 2.10 2.12
85
TC 25.6 25.9 26.5 26.8 26.5 26.8 27.1 27.4 28.3 28.6 28.8 29.0 / 35.5 35.8 36.1
S/T 0.98 1.00 1.00 1.00 0.67 0.90 0.97 1.00 0.39 0.60 0.80 1.00 / 0.38 0.55 0.71
kW 1.71 1.73 1.75 1.75 1.75 1.76 1.78 1.80 1.81 1.83 1.84 1.85 / 2.29 2.31 2.34
95
TC 25.3 25.6 26.2 26.5 26.2 26.5 26.8 27.0 28.0 28.2 28.5 28.7 / 34.2 34.4 34.4
S/T 0.97 1.00 0.99 0.99 0.67 0.90 0.97 1.00 0.39 0.60 0.81 0.99 / 0.38 0.56 0.73
kW 2.03 2.05 2.07 2.07 2.07 2.09 2.12 2.14 2.14 2.16 2.18 2.20 / 2.65 2.65 2.65
105
TC 24.9 25.2 25.8 26.1 25.8 26.1 26.3 26.6 27.6 27.8 28.0 28.3 / 32.2 32.4 32.5
S/T 0.98 1.00 1.00 1.00 0.67 0.90 0.97 1.00 0.39 0.60 0.82 0.99 / 0.39 0.57 0.75
kW 2.39 2.42 2.44 2.44 2.44 2.47 2.50 2.52 2.53 2.55 2.57 2.59 / 2.93 2.93 2.93
115
TC 24.5 24.8 25.4 25.6 25.4 25.6 25.9 26.2 27.1 27.3 27.6 27.8 / 29.6 29.7 29.9
S/T 0.97 1.00 1.00 0.99 0.68 0.90 0.97 1.00 0.39 0.61 0.82 1.00 / 0.39 0.59 0.79
kW 2.83 2.86 2.89 2.89 2.89 2.92 2.95 2.98 2.99 3.01 3.05 3.07 / 3.11 3.12 3.12
125
TC 16.9 17.1 17.5 17.7 17.5 17.7 17.9 18.1 19.0 19.0 19.0 19.1 / 20.3 20.3 20.3
S/T 0.98 1.00 1.00 1.00 0.71 0.90 0.97 1.00 0.40 0.71 1.00 1.00 / 0.41 0.71 0.99
kW 2.08 2.11 2.13 2.13 2.13 2.15 2.17 2.20 2.24 2.24 2.24 2.24 / 2.25 2.25 2.25
Table 8
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input
power
