Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
BOVA 36 + BVA 36 For Cooling
Indoor
Airfl ow (CFM)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
650
15
TC 22.1 22.3 22.8 23.1 22.8 23.1 23.3 23.6 24.4 24.6 24.8 25.1 / 30.1 30.4 30.7
S/T 0.78 0.84 0.92 1.00 0.59 0.77 0.86 0.89 0.40 0.54 0.68 0.82 / 0.39 0.50 0.62
kW 0.84 0.85 0.87 0.87 0.87 0.88 0.89 0.90 0.89 0.90 0.92 0.93 / 1.22 1.24 1.25
65
TC 22.4 22.6 23.1 23.4 23.1 23.4 23.6 23.9 24.7 24.9 25.1 25.4 / 30.4 30.7 31.0
S/T 0.78 0.84 0.92 1.00 0.59 0.77 0.86 0.89 0.40 0.54 0.68 0.82 / 0.39 0.50 0.62
kW 0.94 0.95 0.97 0.97 0.97 0.98 0.99 1.00 0.99 1.00 1.02 1.03 / 1.32 1.34 1.35
75
TC 22.1 22.3 22.8 23.1 22.8 23.1 23.3 23.6 24.3 24.6 24.8 25.0 / 30.4 30.7 31.0
S/T 0.78 0.84 0.92 1.00 0.59 0.76 0.83 0.86 0.40 0.54 0.69 0.83 / 0.39 0.50 0.62
kW 1.18 1.19 1.21 1.21 1.21 1.22 1.23 1.25 1.24 1.26 1.27 1.29 / 1.57 1.58 1.60
85
TC 22.0 22.3 22.8 23.0 22.8 23.0 23.3 23.5 24.3 24.5 24.8 25.0 / 30.2 30.4 30.7
S/T 0.78 0.84 0.92 1.00 0.59 0.76 0.86 0.89 0.40 0.54 0.69 0.83 / 0.39 0.50 0.62
kW 1.32 1.34 1.35 1.35 1.35 1.36 1.38 1.39 1.39 1.41 1.42 1.43 / 1.73 1.75 1.76
95
TC 21.9 22.2 22.6 22.9 22.6 22.9 23.1 23.4 24.2 24.4 24.6 24.8 / 29.8 30.1 30.4
S/T 0.78 0.84 0.92 1.00 0.59 0.77 0.86 0.89 0.40 0.54 0.69 0.83 / 0.39 0.51 0.62
kW 1.60 1.62 1.63 1.63 1.63 1.65 1.67 1.68 1.69 1.70 1.72 1.73 / 2.10 2.12 2.15
105
TC 21.7 22.0 22.5 22.7 22.5 22.7 23.0 23.2 24.0 24.2 24.4 24.7 / 29.5 29.7 30.0
S/T 0.78 0.84 0.92 1.00 0.59 0.77 0.86 0.89 0.40 0.55 0.69 0.83 / 0.39 0.51 0.63
kW 1.92 1.94 1.96 1.96 1.96 1.98 2.00 2.02 2.03 2.04 2.06 2.08 / 2.55 2.57 2.60
115
TC 21.5 21.8 22.3 22.5 22.3 22.5 22.8 23.0 23.8 24.0 24.2 24.4 / 28.1 28.3 28.2
S/T 0.78 0.84 0.92 1.00 0.59 0.77 0.86 0.89 0.40 0.55 0.69 0.84 / 0.39 0.51 0.64
kW 2.28 2.31 2.33 2.33 2.33 2.36 2.38 2.41 2.41 2.44 2.46 2.48 / 2.87 2.87 2.87
125
TC 16.6 16.8 17.2 17.4 17.2 17.4 17.6 17.8 18.6 18.7 18.7 18.7 / 19.8 19.9 19.9
S/T 0.77 0.83 0.91 1.00 0.60 0.77 0.86 0.89 0.40 0.59 0.78 1.00 / 0.40 0.58 0.75
kW 1.87 1.90 1.92 1.92 1.92 1.94 1.96 1.98 2.02 2.02 2.02 2.02 / 2.02 2.02 2.02
820
(Low Stage)
15
TC 24.4 24.7 25.2 25.5 25.2 25.5 25.8 26.1 27.0 27.2 27.5 27.7 / 33.4 33.7 34.0
S/T 0.81 0.87 0.95 1.00 0.61 0.79 0.89 0.92 0.40 0.56 0.71 0.87 / 0.39 0.52 0.64
kW 1.02 1.03 1.05 1.05 1.05 1.06 1.07 1.08 1.08 1.09 1.11 1.12 / 1.48 1.50 1.53
65
TC 24.7 25.0 25.5 25.8 25.5 25.8 26.1 26.4 27.3 27.5 27.8 28.0 / 33.7 34.0 34.3
S/T 0.81 0.87 0.95 1.00 0.61 0.79 0.89 0.92 0.40 0.56 0.71 0.87 / 0.39 0.52 0.64
kW 1.12 1.13 1.15 1.15 1.15 1.16 1.17 1.18 1.18 1.19 1.21 1.22 / 1.58 1.60 1.63
75
TC 24.5 24.8 25.4 25.6 25.4 25.6 25.9 26.2 27.1 27.3 27.6 27.8 / 33.7 34.0 34.3
S/T 0.81 0.87 0.95 1.00 0.61 0.78 0.89 0.92 0.40 0.56 0.71 0.87 / 0.39 0.52 0.64
kW 1.41 1.42 1.44 1.44 1.44 1.45 1.47 1.48 1.48 1.49 1.51 1.53 / 1.76 1.78 1.81
85
TC 24.5 24.8 25.3 25.6 25.3 25.6 25.9 26.1 27.1 27.3 27.5 27.8 / 33.3 33.6 33.8
S/T 0.81 0.87 0.95 1.00 0.61 0.78 0.89 0.92 0.40 0.56 0.72 0.87 / 0.39 0.52 0.65
kW 1.51 1.53 1.54 1.54 1.54 1.56 1.58 1.59 1.60 1.61 1.62 1.64 / 2.00 2.02 2.04
95
TC 24.3 24.6 25.1 25.4 25.1 25.4 25.7 25.9 26.8 27.1 27.3 27.5 / 32.8 33.1 33.3
S/T 0.81 0.87 0.95 1.00 0.61 0.78 0.89 0.92 0.40 0.56 0.71 0.88 / 0.39 0.52 0.65
kW 1.82 1.84 1.86 1.86 1.86 1.88 1.90 1.92 1.92 1.94 1.96 1.97 / 2.43 2.45 2.47
105
TC 24.0 24.3 24.8 25.1 24.8 25.1 25.4 25.7 26.6 26.8 27.0 27.2 / 32.3 32.5 32.7
S/T 0.81 0.87 0.95 1.00 0.61 0.79 0.89 0.92 0.40 0.56 0.72 0.88 / 0.39 0.52 0.66
kW 2.17 2.20 2.22 2.22 2.22 2.24 2.27 2.29 2.30 2.32 2.34 2.36 / 2.91 2.93 2.96
115
TC 23.7 24.0 24.5 24.8 24.5 24.8 25.0 25.3 26.2 26.4 26.6 26.8 / 29.3 28.8 29.0
S/T 0.81 0.87 0.95 1.00 0.61 0.79 0.89 0.92 0.40 0.56 0.73 0.89 / 0.39 0.54 0.69
kW 2.60 2.63 2.66 2.66 2.66 2.69 2.71 2.74 2.75 2.77 2.80 2.82 / 2.93 2.92 2.92
125
TC 16.9 17.1 17.5 17.7 17.5 17.7 17.9 18.1 19.0 19.0 19.0 19.1 / 20.2 20.2 20.3
S/T 0.81 0.87 0.95 1.00 0.61 0.79 0.89 0.92 0.40 0.64 0.88 1.00 / 0.41 0.63 0.85
kW 1.92 1.94 1.96 1.96 1.96 1.98 2.00 2.02 2.06 2.06 2.06 2.06 / 2.07 2.07 2.07
1020
15
TC 29.0 29.3 29.9 30.3 29.9 30.3 30.6 30.9 31.9 32.3 32.6 32.9 / 39.4 39.8 40.1
S/T 0.88 0.92 1.00 1.00 0.63 0.83 0.95 1.00 0.39 0.57 0.74 0.91 / 0.39 0.53 0.66
kW 1.01 1.02 1.03 1.03 1.03 1.04 1.05 1.07 1.06 1.08 1.09 1.10 / 1.39 1.41 1.43
65
TC 29.4 29.7 30.3 30.7 30.3 30.7 31.0 31.3 32.4 32.7 33.0 33.2 / 39.5 39.8 40.1
S/T 0.88 0.92 1.00 1.00 0.61 0.83 0.95 1.00 0.39 0.57 0.73 0.90 / 0.39 0.53 0.67
kW 1.54 1.56 1.57 1.57 1.57 1.59 1.60 1.62 1.62 1.63 1.65 1.67 / 2.04 2.06 2.09
75
TC 29.4 29.8 30.4 30.7 30.4 30.7 31.1 31.4 32.5 32.8 33.1 33.3 / 39.1 39.4 39.7
S/T 0.89 0.93 0.99 1.00 0.62 0.83 0.95 1.00 0.39 0.56 0.73 0.90 / 0.39 0.53 0.67
kW 1.71 1.73 1.75 1.75 1.75 1.77 1.79 1.80 1.79 1.82 1.84 1.86 / 2.25 2.27 2.29
85
TC 29.0 29.3 29.9 30.3 29.9 30.3 30.6 30.9 32.0 32.3 32.6 32.8 / 38.4 38.7 38.9
S/T 0.89 0.93 1.00 1.00 0.62 0.84 0.95 1.00 0.39 0.57 0.74 0.91 / 0.39 0.53 0.67
kW 1.93 1.95 1.97 1.97 1.97 1.99 2.01 2.03 2.03 2.05 2.07 2.09 / 2.55 2.58 2.60
95
TC 28.5 28.8 29.4 29.8 29.4 29.8 30.1 30.4 31.5 31.8 32.0 32.3 / 37.5 37.8 38.0
S/T 0.89 0.93 1.00 1.00 0.62 0.84 0.95 1.00 0.39 0.57 0.74 0.92 / 0.39 0.53 0.68
kW 2.32 2.34 2.37 2.37 2.37 2.39 2.42 2.44 2.45 2.47 2.49 2.52 / 3.04 3.06 3.09
105
TC 27.9 28.3 28.9 29.2 28.9 29.2 29.5 29.8 30.9 31.2 31.4 31.6 / 36.2 36.3 36.5
S/T 0.88 0.92 1.00 1.00 0.62 0.84 0.95 1.00 0.39 0.57 0.75 0.93 / 0.39 0.54 0.69
kW 2.76 2.79 2.82 2.82 2.82 2.85 2.88 2.91 2.91 2.94 2.96 2.99 / 3.52 3.53 3.54
115
TC 25.0 25.3 25.9 26.1 25.9 26.1 26.4 26.7 27.8 28.0 28.1 28.3 / 30.1 30.3 30.4
S/T 0.89 0.93 1.00 1.00 0.62 0.85 0.95 1.00 0.40 0.60 0.79 0.99 / 0.39 0.58 0.76
kW 2.81 2.84 2.87 2.87 2.87 2.91 2.94 2.97 2.99 3.01 3.03 3.04 / 3.13 3.15 3.16
125
TC 17.1 17.3 17.7 17.9 17.7 17.9 18.1 18.3 19.2 19.2 19.2 19.3 / 20.5 20.5 20.5
S/T 0.89 0.93 1.00 0.99 0.70 1.00 0.95 1.00 0.41 0.70 0.99 1.00 / 0.42 0.69 0.99
kW 1.97 2.00 2.02 2.02 2.02 2.04 2.06 2.08 2.12 2.12 2.12 2.12 / 2.13 2.13 2.13
Table 9
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
