Service Manual Bosch IDS 2.0 | 17
Bosch Thermotechnology Corp. | 07.2021
Data subject to change
BOVA 36 + BVA 36 For Cooling
Indoor
Airfl ow (CFM)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
1150
(High Stage)
15
TC 31.3 31.6 32.3 32.7 32.3 32.7 33.0 33.4 34.5 34.8 35.2 35.5 / 42.8 43.1 43.5
S/T 0.89 0.94 1.00 1.00 0.64 0.86 0.96 1.00 0.39 0.58 0.76 0.94 / 0.38 0.54 0.68
kW 1.16 1.18 1.19 1.19 1.19 1.20 1.21 1.23 1.22 1.24 1.25 1.27 / 1.64 1.66 1.68
65
TC 31.6 31.9 32.7 33.0 32.7 33.0 33.4 33.7 35.0 35.2 35.5 35.8 / 42.2 42.5 42.8
S/T 0.89 0.94 1.00 1.00 0.63 0.86 0.96 1.00 0.39 0.58 0.76 0.94 / 0.39 0.54 0.69
kW 1.80 1.82 1.84 1.84 1.84 1.86 1.88 1.90 1.89 1.92 1.94 1.96 / 2.34 2.37 2.39
75
TC 31.6 32.0 32.7 33.0 32.7 33.0 33.4 33.8 35.0 35.3 35.5 35.8 / 41.9 42.2 42.5
S/T 0.90 0.94 1.00 1.00 0.62 0.85 0.96 1.00 0.39 0.58 0.76 0.94 / 0.39 0.54 0.69
kW 1.97 1.99 2.01 2.01 2.01 2.03 2.05 2.07 2.07 2.09 2.12 2.14 / 2.46 2.49 2.51
85
TC 31.1 31.4 32.1 32.5 32.1 32.5 32.8 33.2 34.4 34.7 34.9 35.2 / 40.8 41.1 41.4
S/T 0.90 0.94 1.00 1.00 0.63 0.86 0.96 1.00 0.39 0.58 0.76 0.95 / 0.39 0.54 0.70
kW 2.17 2.19 2.22 2.22 2.22 2.24 2.26 2.29 2.29 2.31 2.33 2.36 / 2.84 2.86 2.89
95
TC 30.7 31.1 31.8 32.1 31.8 32.1 32.4 32.8 33.7 34.2 34.5 34.7 / 39.8 40.0 40.2
S/T 0.90 0.94 0.99 1.00 0.63 0.87 0.96 1.00 0.39 0.58 0.76 1.00 / 0.39 0.55 0.71
kW 2.58 2.61 2.64 2.64 2.64 2.66 2.69 2.72 2.73 2.75 2.78 2.80 / 3.34 3.37 3.39
105
TC 29.9 30.3 31.0 31.3 31.0 31.3 31.6 32.0 33.0 33.4 33.6 33.9 / 36.9 36.9 37.1
S/T 0.89 0.94 0.99 1.00 0.63 0.87 0.96 1.00 0.39 0.59 0.78 1.00 / 0.39 0.57 0.74
kW 3.05 3.08 3.11 3.11 3.11 3.15 3.18 3.21 3.22 3.25 3.28 3.30 / 3.61 3.59 3.61
115
TC 24.8 25.1 25.6 25.9 25.6 25.9 26.2 26.5 28.2 28.3 27.9 28.0 / 29.1 29.2 29.3
S/T 0.90 0.94 1.00 1.00 0.64 0.88 0.96 1.00 0.40 0.62 0.86 1.00 / 0.40 0.62 0.84
kW 2.86 2.89 2.92 2.92 2.92 2.95 2.98 3.01 3.06 3.08 3.07 3.09 / 3.12 3.13 3.14
125
TC 17.2 17.4 17.8 18.0 17.8 18.0 18.2 18.4 19.3 19.3 19.3 19.4 / 20.6 20.6 20.6
S/T 0.89 0.94 0.99 1.00 0.75 1.00 0.96 0.99 0.41 0.75 1.00 1.00 / 0.43 0.74 1.00
kW 2.03 2.05 2.07 2.07 2.07 2.09 2.11 2.14 2.18 2.18 2.18 2.18 / 2.18 2.18 2.18
1350
15
TC 34.2 34.6 35.4 35.8 35.4 35.8 36.2 36.5 37.8 38.1 38.5 38.8 / 45.0 45.3 45.7
S/T 0.89 0.93 1.00 1.00 0.64 0.89 1.00 1.00 0.39 0.58 0.78 1.00 / 0.38 0.54 0.70
kW 1.41 1.43 1.45 1.45 1.45 1.46 1.48 1.49 1.49 1.50 1.52 1.54 / 2.01 2.03 2.06
65
TC 33.6 34.0 34.7 35.1 34.7 35.1 35.5 35.9 37.2 37.5 37.7 38.0 / 44.5 44.8 45.5
S/T 0.89 0.93 1.00 1.00 0.64 0.88 0.96 1.00 0.39 0.59 0.78 0.99 / 0.38 0.55 0.71
kW 2.11 2.13 2.15 2.15 2.15 2.18 2.20 2.22 2.22 2.24 2.27 2.29 / 2.68 2.70 2.56
75
TC 33.7 34.1 34.9 35.2 34.9 35.2 35.6 36.0 37.4 37.6 37.9 38.2 / 45.6 45.8 45.9
S/T 0.89 0.94 1.00 1.00 0.63 0.88 0.96 1.00 0.39 0.59 0.78 1.00 / 0.38 0.55 0.71
kW 2.17 2.19 2.22 2.22 2.22 2.24 2.26 2.29 2.29 2.31 2.33 2.36 / 2.95 2.96 2.96
85
TC 33.0 33.4 34.1 34.5 34.1 34.5 34.8 35.2 36.6 36.8 37.1 37.3 / 43.0 43.2 43.5
S/T 0.89 0.94 1.00 1.00 0.64 0.89 0.96 1.00 0.39 0.59 0.79 1.00 / 0.39 0.56 0.73
kW 2.45 2.47 2.50 2.50 2.50 2.53 2.55 2.58 2.59 2.61 2.63 2.65 / 3.15 3.18 3.20
95
TC 32.2 32.5 33.2 33.6 33.2 33.6 34.0 34.3 35.7 35.9 36.1 36.4 / 40.9 41.1 41.1
S/T 0.90 0.94 1.00 1.00 0.64 0.90 0.96 1.00 0.39 0.60 0.80 1.00 / 0.39 0.57 0.75
kW 2.88 2.91 2.94 2.94 2.94 2.97 3.00 3.03 3.05 3.07 3.09 3.11 / 3.56 3.57 3.57
105
TC 31.3 31.6 32.3 32.7 32.3 32.7 33.0 33.4 34.7 34.9 35.1 35.4 / 37.4 37.6 37.4
S/T 0.90 0.94 1.00 1.00 0.65 0.90 0.96 1.00 0.39 0.60 0.81 1.00 / 0.39 0.59 0.79
kW 3.36 3.39 3.43 3.43 3.43 3.47 3.50 3.54 3.56 3.59 3.61 3.64 / 3.74 3.76 3.70
115
TC 25.0 25.2 25.8 26.1 25.8 26.1 26.4 26.6 27.8 27.9 28.0 28.2 / 29.8 29.9 30.0
S/T 0.90 0.94 1.00 1.00 0.66 1.00 0.96 1.00 0.40 0.66 0.93 1.00 / 0.40 0.65 0.90
kW 2.97 3.00 3.04 3.04 3.04 3.07 3.10 3.13 3.17 3.18 3.20 3.21 / 3.31 3.32 3.33
125
TC 17.2 17.4 17.8 18.0 17.8 18.0 18.2 18.4 19.3 19.3 19.4 19.4 / 20.6 20.6 20.6
S/T 0.89 0.94 1.00 1.00 0.79 1.00 0.96 1.00 0.41 0.80 1.00 1.00 / 0.43 0.80 0.99
kW 2.11 2.14 2.16 2.16 2.16 2.18 2.20 2.23 2.27 2.27 2.27 2.27 / 2.28 2.28 2.28
Table 10
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power

Bosch IDS 2.0 Specifications

General

Refrigerant	R-410A
Stages	Variable
Voltage	208/230 V
System Type	Air Source Heat Pump
Compressor Type	Inverter-driven
Sound Level	As low as 56 dB
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Noise Level	45 dB to 60 dB
Operating Temperature Range (Heating)	-20°C to 35°C
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Seasonal Coefficient of Performance (SCOP)	Not Available
