Bosch IDS 2.0 User Manual

18
|
Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
BOVA 60 +BVA 48 For Cooling
Indoor
Airfl ow (CFM)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
1180
(Low Stage)
15
TC 39.0 39.4 40.3 40.7 40.3 40.7 41.2 41.6 43.0 43.4 43.8 44.1 / 52.2 52.6 53.6
S/T 0.84 0.89 0.96 1.00 0.59 0.79 0.91 0.95 0.40 0.55 0.69 0.84 / 0.39 0.51 0.63
kW 1.25 1.27 1.29 1.29 1.29 1.31 1.33 1.35 1.34 1.36 1.39 1.40 / 1.97 2.00 1.79
65
TC 38.9 39.3 40.2 40.6 40.2 40.6 41.1 41.5 42.9 43.3 43.7 44.0 / 52.1 52.5 53.5
S/T 0.84 0.89 0.96 1.00 0.59 0.79 0.91 0.95 0.40 0.55 0.69 0.84 / 0.39 0.51 0.63
kW 1.85 1.87 1.89 1.89 1.89 1.91 1.93 1.95 1.94 1.96 1.99 2.00 / 2.57 2.60 2.39
75
TC 38.6 39.1 39.9 40.4 39.9 40.4 40.8 41.2 42.6 43.0 43.4 43.8 / 51.6 52.2 52.6
S/T 0.84 0.89 0.96 1.00 0.59 0.79 0.91 0.95 0.40 0.55 0.69 0.84 / 0.39 0.51 0.63
kW 2.09 2.11 2.13 2.13 2.13 2.16 2.18 2.20 2.20 2.22 2.25 2.27 / 2.69 2.60 2.62
85
TC 38.2 38.6 39.5 39.9 39.5 39.9 40.3 40.7 42.6 42.8 42.9 43.3 / 51.0 51.4 51.8
S/T 0.84 0.89 0.96 1.00 0.59 0.79 0.91 0.95 0.40 0.55 0.70 0.85 / 0.39 0.51 0.63
kW 2.22 2.25 2.27 2.27 2.27 2.29 2.32 2.34 2.38 2.39 2.39 2.41 / 2.94 2.96 2.99
95
TC 37.8 38.2 39.1 39.5 39.1 39.5 39.9 40.4 41.7 42.2 42.5 42.8 / 50.2 50.6 50.9
S/T 0.84 0.89 0.96 1.00 0.60 0.79 0.91 0.95 0.40 0.55 0.70 0.85 / 0.39 0.51 0.64
kW 2.69 2.72 2.75 2.75 2.75 2.78 2.81 2.84 2.84 2.87 2.89 2.92 / 3.52 3.55 3.58
105
TC 37.4 37.8 38.6 39.0 38.6 39.0 39.5 39.9 41.3 41.6 42.0 42.3 / 49.3 49.6 49.9
S/T 0.84 0.89 0.96 1.00 0.60 0.79 0.91 0.95 0.39 0.55 0.70 0.86 / 0.39 0.51 0.64
kW 3.22 3.26 3.29 3.29 3.29 3.32 3.36 3.39 3.41 3.44 3.46 3.49 / 4.19 4.23 4.26
115
TC 36.8 37.2 38.1 38.5 38.1 38.5 38.9 39.3 40.7 41.0 41.4 41.7 / 44.9 45.1 45.4
S/T 0.84 0.89 0.96 1.00 0.60 0.80 0.91 0.95 0.40 0.55 0.71 0.86 / 0.39 0.53 0.67
kW 3.84 3.88 3.92 3.92 3.92 3.96 4.00 4.04 4.05 4.08 4.13 4.16 / 4.34 4.35 4.35
125
TC 29.5 29.9 30.5 30.8 30.5 30.8 31.2 31.5 33.0 33.1 33.2 33.2 / 35.1 35.2 35.3
S/T 0.86 0.91 0.98 1.00 0.60 0.81 0.92 0.96 0.40 0.59 0.79 1.00 / 0.39 0.58 0.76
kW 3.13 3.16 3.19 3.19 3.19 3.23 3.26 3.29 3.36 3.36 3.36 3.36 / 3.38 3.38 3.39
1330
15
TC 40.9 41.4 42.3 42.8 42.3 42.8 43.2 43.7 45.1 45.6 46.0 46.4 / 55.3 55.7 56.2
S/T 0.89 0.93 1.00 1.00 0.61 0.82 0.95 1.00 0.39 0.55 0.71 0.87 / 0.38 0.52 0.64
kW 1.33 1.35 1.36 1.36 1.36 1.38 1.39 1.41 1.38 1.40 1.43 1.46 / 1.74 1.75 1.77
65
TC 40.6 41.0 41.9 42.4 41.9 42.4 42.9 43.3 45.3 45.4 45.6 46.0 / 55.3 55.7 56.2
S/T 0.89 0.93 1.00 1.00 0.60 0.81 0.95 1.00 0.39 0.55 0.71 0.87 / 0.38 0.52 0.64
kW 2.01 2.03 2.05 2.05 2.05 2.07 2.09 2.11 2.14 2.15 2.16 2.19 / 2.58 2.61 2.64
75
TC 40.8 41.2 42.1 42.6 42.1 42.6 43.1 43.5 45.0 45.4 45.8 46.2 / 55.0 55.4 55.8
S/T 0.89 0.93 1.00 1.00 0.60 0.81 0.95 1.00 0.39 0.55 0.71 0.87 / 0.38 0.52 0.65
kW 2.17 2.19 2.22 2.22 2.22 2.24 2.26 2.29 2.28 2.31 2.33 2.36 / 2.80 2.83 2.86
85
TC 40.2 40.7 41.6 42.0 41.6 42.0 42.5 42.9 44.4 44.8 45.2 45.6 / 54.1 54.5 54.9
S/T 0.89 0.93 1.00 1.00 0.60 0.81 0.95 1.00 0.39 0.56 0.72 0.88 / 0.38 0.52 0.65
kW 2.41 2.44 2.46 2.46 2.46 2.49 2.52 2.54 2.55 2.57 2.59 2.62 / 3.16 3.19 3.22
95
TC 39.7 40.2 41.1 41.5 41.1 41.5 42.0 42.4 43.9 44.3 44.6 45.0 / 53.0 53.4 53.8
S/T 0.89 0.93 1.00 1.00 0.61 0.81 0.95 1.00 0.39 0.56 0.72 0.88 / 0.38 0.52 0.66
kW 2.90 2.93 2.96 2.96 2.96 2.99 3.02 3.05 3.06 3.09 3.12 3.14 / 3.77 3.80 3.83
105
TC 39.1 39.6 40.5 40.9 40.5 40.9 41.3 41.8 43.3 43.6 44.0 44.3 / 51.9 52.3 52.6
S/T 0.89 0.93 1.00 1.00 0.61 0.82 0.95 1.00 0.39 0.56 0.73 0.89 / 0.38 0.52 0.66
kW 3.45 3.49 3.53 3.53 3.53 3.57 3.60 3.64 3.65 3.68 3.71 3.74 / 4.48 4.52 4.55
115
TC 38.3 38.8 39.6 40.0 39.6 40.0 40.5 40.9 42.6 42.9 43.1 43.0 / 45.3 45.5 45.7
S/T 0.89 0.93 1.00 1.00 0.61 0.83 0.95 1.00 0.39 0.56 0.73 0.90 / 0.39 0.55 0.71
kW 4.07 4.11 4.15 4.15 4.15 4.20 4.24 4.28 4.33 4.36 4.37 4.36 / 4.39 4.41 4.43
125
TC 29.7 30.0 30.7 31.1 30.7 31.1 31.4 31.7 33.3 33.3 33.4 33.5 / 35.4 35.5 35.5
S/T 0.90 0.94 1.00 1.00 0.63 0.86 0.96 1.00 0.40 0.62 0.83 1.00 / 0.40 0.60 0.81
kW 3.18 3.21 3.25 3.25 3.25 3.28 3.31 3.35 3.42 3.42 3.42 3.42 / 3.44 3.44 3.44
1530
(High Stage)
15
TC 43.8 44.3 45.3 45.8 45.3 45.8 46.3 46.8 48.3 48.8 49.2 49.7 / 58.7 59.2 59.6
S/T 0.90 0.94 1.00 1.00 0.62 0.84 0.96 1.00 0.39 0.56 0.73 0.90 / 0.38 0.53 0.67
kW 1.65 1.67 1.68 1.68 1.68 1.70 1.72 1.74 1.70 1.74 1.77 1.80 / 2.14 2.16 2.18
65
TC 43.2 43.7 44.6 45.1 44.6 45.1 45.6 46.1 47.7 48.1 48.5 48.9 / 58.5 58.9 59.4
S/T 0.90 0.94 1.00 1.00 0.61 0.84 0.96 1.00 0.39 0.57 0.74 0.91 / 0.38 0.53 0.67
kW 2.30 2.33 2.35 2.35 2.35 2.37 2.40 2.42 2.41 2.44 2.47 2.50 / 2.92 2.95 2.98
75
TC 43.4 43.9 44.8 45.3 44.8 45.3 45.8 46.3 47.9 48.3 48.7 49.1 / 58.1 58.5 58.9
S/T 0.90 0.94 1.00 1.00 0.62 0.84 0.96 1.00 0.39 0.57 0.74 0.91 / 0.38 0.53 0.67
kW 2.44 2.47 2.50 2.50 2.50 2.52 2.55 2.58 2.57 2.60 2.63 2.65 / 3.11 3.13 3.16
85
TC 42.7 43.2 44.2 44.7 44.2 44.7 45.1 45.6 47.2 47.7 48.0 48.4 / 57.0 57.5 57.9
S/T 0.90 0.94 1.00 1.00 0.62 0.84 0.96 1.00 0.39 0.57 0.74 0.91 / 0.38 0.53 0.67
kW 2.67 2.70 2.73 2.73 2.73 2.76 2.78 2.81 2.82 2.85 2.87 2.90 / 3.47 3.50 3.52
95
TC 42.2 42.7 43.7 44.1 43.7 44.1 44.6 45.1 46.6 47.0 47.5 47.8 / 55.8 56.2 56.6
S/T 0.90 0.94 1.00 1.00 0.62 0.84 0.96 1.00 0.39 0.57 0.75 0.92 / 0.38 0.53 0.68
kW 3.18 3.21 3.25 3.25 3.25 3.28 3.32 3.35 3.37 3.39 3.42 3.45 / 4.12 4.16 4.19
105
TC 41.4 41.9 42.8 43.3 42.8 43.3 43.7 44.2 45.7 46.2 46.5 46.9 / 54.5 54.8 55.1
S/T 0.90 0.94 1.00 1.00 0.62 0.85 0.96 1.00 0.39 0.57 0.75 0.93 / 0.38 0.54 0.69
kW 3.77 3.81 3.85 3.85 3.85 3.89 3.93 3.97 3.98 4.02 4.05 4.08 / 4.87 4.90 4.93
115
TC 38.9 39.3 40.2 40.6 40.2 40.6 41.1 41.5 43.3 43.4 43.7 43.4 / 46.7 46.9 47.1
S/T 0.90 0.94 1.00 1.00 0.62 0.86 0.96 1.00 0.39 0.59 0.78 1.00 / 0.39 0.57 0.75
kW 4.19 4.23 4.28 4.28 4.28 4.32 4.37 4.41 4.49 4.48 4.50 4.45 / 4.62 4.64 4.65
125
TC 29.9 30.2 30.9 31.2 30.9 31.2 31.6 31.9 33.5 33.5 33.6 33.6 / 35.6 35.7 35.8
S/T 0.91 0.96 1.00 1.00 0.65 0.92 0.96 1.00 0.40 0.65 0.90 0.99 / 0.40 0.64 0.87
kW 3.26 3.29 3.33 3.33 3.33 3.36 3.40 3.43 3.50 3.50 3.50 3.51 / 3.53 3.53 3.53
Table 11
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power

Bosch IDS 2.0 Specifications

General

Refrigerant	R-410A
Stages	Variable
Voltage	208/230 V
System Type	Air Source Heat Pump
Compressor Type	Inverter-driven
Sound Level	As low as 56 dB
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Noise Level	45 dB to 60 dB
Operating Temperature Range (Heating)	-20°C to 35°C
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Seasonal Coefficient of Performance (SCOP)	Not Available
