MIC IP ultra 7100i │ MIC IP starlight 7100i Table of contents | en 3
Bosch Security Systems Installation Manual 2019-12 | 1.2 |
Table of contents
1
Safety 4
1.1 About this Manual 4
1.2 Legal Information 4
1.3 Safety Precautions 5
1.4 Important Safety Instructions 6
1.5 Important Notices 8
1.6 Important Notices - Illumination Safety 11
1.7 Customer Support and Service 12
2
Introduction 13
2.1 Configuration with Project Assistant app 13
2.2 Parts List - Camera 13
2.3 Additional Tools 14
3
Product Description 15
4
Overview of Installation Steps 16
5
Mounting 17
5.1 Mounting Location and Orientation Options 17
5.2 Mounting Options 18
5.3 Mounting Bracket Options 20
5.4 Considerations for Mounting the Camera in Inverted Orientation 21
6
(Optional) Installing an SD card 23
7
(Optional) Configuration Programming in the Shipping Box 24
8
(Optional) Configuration Programming on a Temporary Table-top Stand 25
9
Installing a MIC Camera on a Hinged DCA 26
10
(Optional) Installing a Sunshield 32
11
(Optional) Installing the Illuminator 35
12
(Optional) Canting the Camera 38
13
Replacing a wiper assembly 42
14
Connections 49
14.1 About Camera Power and Control 49
14.2 Power Source Options 49
14.3 Ethernet Connections 50
14.4 Camera Connections 50
14.5 Connect the Camera to the Network 50
15
Typical System Configurations 51
15.1 Typical IP Configuration with High PoE midspan (no I/O connections) 51
15.2 Typical Configuration with MIC-ALM-WAS-24 52
16
Troubleshooting 53
16.1 Physical reset button 53
17
Maintenance 55
18
Disposal 56
19
Technical data 57
20
Best Practices for Outdoor Installation 58
21
Error Codes 60
22
AUX Commands 65
