34 en | (Optional) Installing a Sunshield MIC IP ultra 7100i │ MIC IP starlight 7100i
2019-12 | 1.2 | Installation Manual Bosch Security Systems
M4 x 8
2.2 N m
(19.5 in lb)
T20
2
6. Note that when you install the sunshield correctly, the sunshield appears as in the
following figure.
Figure10.1: Sunshield installation is complete.
