NL Getting to know your device
YOU5 Getting to know your deviceget to know your device
Getting to know your device
5.1 Device
Here you will find an overview of the components of your device.
3 4
5 6
2
7
7
1
8
Depending on the device type, details in the picture may differ,
e.g. the color and the shape.
1
Service valve and pump
Page 42
7
8
Transport protections
Page 14
2
3
4
Door
Detergent drawer
Page 19
Water supply hose
Page 15
Control panel
Page 19
5
6
Water drain hose
Page 16
Mains connection cable
Page 17
18
