WATER PRESSURE DROP WW
Chilled Fluid Side (55°F) Cond. Fluid Side (85°F)
Model
GPM
Pressure Drop (PSIG) Pressure Drop (ft of
H2O)
Pressure Drop
(PSIG)
Pressure Drop (ft
of H2O)
120
18.0
2.36 5.5 2.05 4.7
22.0
3.39 7.8 2.94 6.8
26.0
4.58 10.6 3.97 9.2
30.0
5.93 13.7 5.14 11.9
34.0
7.43 17.1 6.44 14.8
122
18.0
2.36 5.5 2.05 4.7
22.0
3.39 7.8 2.94 6.8
26.0
4.58 10.6 3.97 9.2
30.0
5.93 13.7 5.14 11.9
34.0
7.43 17.1 6.44 14.8
180
22.0
2.04 4.7 1.70 3.9
26.0
2.75 6.3 2.29 5.3
30.0
3.56 8.2 2.96 6.8
34.0
4.46 10.3 3.71 8.6
38.0
5.44 12.6 4.54 10.5
210
25.0
2.56 5.9 2.13 4.9
30.0
3.56 8.2 2.96 6.8
35.0
4.69 10.8 3.91 9.0
40.0
5.97 13.8 4.98 11.5
45.0
7.38 17.0 6.15 14.2
240
36.0
2.36 5.4 2.06 4.7
44.0
3.39 7.8 2.95 6.8
52.0
4.57 10.6 3.99 9.2
60.0
5.92 13.7 5.16 11.9
68.0
7.41 17.1 6.47 14.9
360
44.0
2.05 4.7 1.69 3.9
52.0
2.77 6.4 2.29 5.3
60.0
3.58 8.3 2.96 6.8
68.0
4.48 10.3 3.71 8.6
76.0
5.48 12.6 4.53 10.4
420
50.0
2.58 5.9 2.13 4.9
60.0
3.58 8.3 2.96 6.8
70.0
4.72 10.9 3.91 9.0
80.0
6.01 13.9 4.97 11.5
90.0
7.42 17.1 6.14 14.2
