Bosch WT Series - Water Pressure Drop WT; WT Model Pressure Drop Data

Water Pressure Drop WT | 29WW & WT Models
8733943362 (2016/08)Revised 08-16
WATER PRESSURE DROP WT
Chilled Fluid Side (55°F) Cond. Fluid Side (85°F)
Model
GPM
Pressure Drop
(PSIG)
Pressure Drop (ft
of H2O)
Pressure Drop
(PSIG)
Pressure Drop (ft
of H2O)
025
3.0 0.56 1.30 0.51 1.18
4.0
0.95 2.18 0.86 1.98
5.0
1.41 3.26 1.28 2.95
6.0
1.96 4.52 1.78 4.10
8.0
3.29 7.59 2.98 6.88
035
4.5
1.85 4.26 1.67 3.86
6.0
3.10 7.14 2.81 6.47
7.5
4.63 10.68 4.19 9.67
9.0
6.43 14.82 5.82 13.43
12.0
10.78 24.88 9.77 22.54
049
6.0
1.10 2.54 1.00 2.30
8.0
1.85 4.26 1.67 3.86
10.0
2.76 6.37 2.50 5.77
12.0
3.83 8.85 3.47 8.01
16.0
6.44 14.85 5.83 13.45
061
7.5
1.41 3.24 1.27 2.94
10.0
2.36 5.44 2.14 4.93
12.5
3.53 8.13 3.19 7.37
15.0
4.89 11.29 4.43 10.23
20.0
8.21 18.95 7.44 17.17
071
9.0
2.01 4.65 1.83 4.23
12.0
3.38 7.80 3.08 7.10
15.0
5.05 11.65 4.60 10.60
18.0
7.01 16.18 6.38 14.72
24.0
11.77 27.15 10.71 24.71
All values based upon pure water at the indicated
temperature.
