13
SPECIFICATIONS
Technical Specifications
Power Rating
PS602 PS602P PS604
Amplifier Power 2 x 300 W @ 4-8 Ω, 70/100 V 2 x 300 W @ 4-8 Ω, 70/100 V 4 x 150 W @ 4-8 Ω, 70/100 V
Audio Performance
Frequency Response 4-8 Ω: 20 Hz – 20 kHz (+0/–1 dB, @ 1 W 4 Ω); 70/100 V: 50 Hz - 20 kHz (+0.5/-0.5 dB, @ 1 W)
THD+N ≤ 0.1 % (1 kHz, at rated full power, 8Ω); ≤ 0.5% (1 kHz, at rated full power, 70/100 V)
Channel Separation
(Crosstalk)
>75 dB @ 1 kHz, >55 dB @ 20 kHz
Dynamic Range 98 dB, 4 Ω
Integrated DSP
A/D and D/A Converters 24-bit / 48 kHz
Processing Functions Standard mixer, loudspeaker EQ, room EQ, Vpeak/Vrms limiters, delay, crossover, phase inversion (per channel)
Loudspeaker Presets DS 16, DS 40, DS 100, FS3B, Panaray® 402 and 802 Series IV, MA12X, RoomMatch® Utility RMU105, Flat
Audio Latency 14 ms (any input to speaker output)
Audio Inputs
PS602 PS602P PS604
Input Channels 2 unbalanced, 2 balanced 2 unbalanced, 2 balanced 4 balanced
Connectors Stereo RCA, 3-pin Euroblock Stereo RCA, XLR with 1/4” combo 3-pin Euroblock
Input Range 4 to 20 dBu (Euroblock);
-10 to 6 dBV (RCA)
4 to 20 dBu (Euroblock);
-10 to 6 dBV (RCA)
4 to 20 dBu (Euroblock)
Adjustment Range (RCA) -10 to -2 dBV, -2 to 6 dBV (RCA) -10 to -2 dBV, -2 to 6 dBV (RCA) N/A
Adjustment Range
(Euroblock)
4 to 12 dBu, 12 to 20 dBu 4 to 12 dBu, 12 to 20 dBu 4 to 12 dBu, 12 to 20 dBu
Input Impedance 10 kΩ (RCA), 20 kΩ (Euroblock, XLR)
Maximum Input Level 6 dBV / 8.2 dBu (RCA); 20 dBu (Euroblock)
Sensitivity -10 dBV / -7.8 dBu (RCA), 4 dBu (Euroblock)
Audio Outputs
PS602 PS602P PS604
Outputs 2 2 4
Connectors 2-pin inverted Euroblock NL4 & binding posts 2-pin inverted Euroblock
Indicators and Controls
Power LED Solid green indicates power is on. Blinking green indicates standby mode. Solid amber indicates an over-
temperature fault. Solid red indicates a power supply fault.
Input Signal LED See Front and Rear Panel section for each amplifier for details.
Output Limit LED See Front and Rear Panel section for each amplifier for details.
Controls, Front Panel
Controls, Rear Panel Amplifier mode DIP switches, loudspeaker EQ dials, output trims (PS602 and PS604 only)
Electrical
Mains Voltage 100 VAC – 240 VAC (±10%, 50/60 Hz)
AC Power Consumption 120 VAC: 79 W (Standby), 324 W (Max) 230 VAC: 88 W (Standby), 384 W (Max)
Mains Connector Standard IEC (C14)
Maximum Inrush Current PS602: 12.33 A (230 VAC / 50 Hz), 8.27 A (120 VAC / 60 Hz)
PS602P: 14.14 A (230 VAC / 50 Hz), 8.04 A (120 VAC / 60 Hz)
PS604: 11.79 A (230 VAC / 50 Hz), 11.72 A (120 VAC / 60 Hz)
Overload Protection High temperature, output short, excessively low or high AC line voltage
Physical
Dimensions 44 mm H x 483 mm W x 414 mm D (1.7" H x 19.0" W x 16.3" D)
Shipping Weight PS602 and PS602P: 6.9 kg (15.3 lb); PS604: 7.8 kg (17.2 lb)
Net Weight PS602 and PS602P: 5.5 kg (12.2 lb); PS604: 6.4 kg (14.1 lb)
Cooling System Variable speed fans create continuous left-to-right air flow
General
Inputs (Control) RJ-45 remote input for volume control using the CC-1 ControlCenter Zone Controllers (PS602 and PS604 only),
or for connection to the CV41. USB input for configuring the amplifier with PowerShare Editor Software. Mute
input control via a normally open contact closure
