MAIN PART LIST

PowerShare

PS602P (refer to Figure 3)

Item

Number

Description Part Numbe

Qty. Note

1 ASSY, TOP COVER, K2/K2P, SVCE 748388-011S 1

2 SCREW, TOP COVER - 12

3 FAN, DC 5V, 5400 RPM 748033-001S 2

4 PCB ASSY, P/S, K2, K2P, SVCE 747922-001S 1

5 SWITCH, ON-OFF 748030-0010 1 3

6 PUSH KNOB 748029-0110 1

7 BEZEL, PLASTIC, FRONT, AMP, K2P, SVCE 747903-012S 1

8 KNOB, VOLUME 768036-011S 2

9 PANEL, FRONT, AMP, K2P, SVCE 747851-012S 1

10 RACK EAR, FRONT 748545-011S 2

11 PCB ASSY, AMPLIFIER 732946-0010 1

12 PCB ASSY, DSP, K2P, SVCE 748233-001S 1

13 BRACKET, REAR 747855-011S 2

14 PCB ASSY, REAR PANEL INPUT, K2P, SVCE 748296-001S 1

15 PCB ASSY, REAR, K2P, SVCE 748294-001S 1

16 PCB ASSY, REAR PANEL OUTPUT, K2P, SVCE 748291-001S 1

17 CONN, ASSY, IEC, FS4400, SERVICE 301396 1 3

- PCB ASSY, LED, K2P, SVCE 747986-001S 1

- ASSY, SWITCH AND BUTTON W/HARNESS, SVCE 748075-001S 1 3

- ASSY, CABLE FCC, AMP TO DSP, 95LG, 10-PIN 765531-001S 1

- ASSY, CABLE FCC, AMP TO DSP, 250LG, 20-PIN 765532-002S 1

- ASSY, CABLE FCC, R PNL TO DSP, 130LG, 20-PIN 765535-002S 2

- ASSY, CABLE FCC, R PNL TO DSP, 150LG, 20-PIN 765535-003S 1

- ASSY, HARNESS, DSP TO PS, 70LG, 6-PIN 765536-001S 1

- ASSY, HARNESS, AMP TO PS, 3-PIN 765538-001S 1

- ASSY, CABLE, GROUND INLET 765540-001S 1 3

- ASSY, HARNESS, IEC TO SWITCH 765541-001S 1 3

- ASSY, CABLE, SWITCH TO PS 774336-001S 1 3
