Bose PowerShare PS602P Service Manual

47
ELECTRICAL PART LIST
Resistors
Rear Panel PCB Assembly, PS602
Reference
Designator
Description
V
endor Part Number Note
R701 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R706 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R707 RMG, 1/10W, 5.1K, 1%, 0805 4720-512A+J
R708 RMG, 1/10W, 5.1K, 1%, 0805 4720-512A+J
R710 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R711 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R734 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R735 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R745 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R747 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R756 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R757 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R758 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R759 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R760 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R761 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R762 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R763 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R764 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R767 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R769 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R770 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R772 RMG, 1/16W, 470K, 1%, 0603 4723-474A+P
R773 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R774 RMG, 1/16W, 3K, 1%, 0603 4723-302A+P
R775 RMG, 1/16W, 3K, 1%, 0603 4723-302A+P
R776 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R777 RMG, 1/16W, 470K, 1%, 0603 4723-474A+P
R778 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R779 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R780 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R781 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R782 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R783 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R784 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R785 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R786 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R787 RMG, 1/16W, 10K, 1%, 0603, HK 4723-103A+P-R
R805 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R806 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R812 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R813 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R814 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R815 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R816 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R817 RMG, 1/10W, 100 OHM, 1%, 0805 4720-101A+J
R818 RMG, 1/16W, 4.7K, 1%, 0603/1608. 4723-472A+P
R852 RMG, 1/16W, 7.15K, 1%, 0603/1608 4723-7151+P
R853 RMG, 1/16W, 8.87K, 1%, 0603/1608 4723-8871+P
R854 RMG, 1/16W, 8.87K, 1%, 0603/1608 4723-8871+P
R855 RMG, 1/16W, 7.15K, 1%, 0603/1608 4723-7151+P
R860 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
