MAIN PART LIST

PowerShare

PS604 (refer to Figure 4)

Item

Number

Description Part Numbe

Qty. Note

1 ASSY, TOP COVER, K2/K2P/K4, SVCE 748388-011S 1

2 SCREW, TOP COVER - 12

3 FAN, DC 5V, 5400 RPM 748033-001S 2

4 PCB ASSY, P/S, K4, SVCE 747922-001S 1

5 SWITCH, ON-OFF 748030-0010 1 3

6 PUSH KNOB 748029-0110 1

7 BEZEL, PLASTIC, FRONT, AMP, K4, SVCE 747903-013S 1

8 PANEL, FRONT, AMP, K4, SVCE 747851-013S 1

9 RACK EAR, FRONT 748545-011S 2

10 PCB ASSY, AMPLIFIER 732946-0010 2

11 PCB, ASSY, DSP, K4, SVCE 748560-001S 1

12 BRACKET, REAR 747855-011S 2

13 PCB ASSY, REAR, K4, SVCE 747968-001S 1

14 CONN, ASSY, IEC, FS4400, SERVICE 301396 1 3

- PCB ASSY, REAR PANEL OUTPUT, K4, SVCE 748568-001S 1

- PCB ASSY, LED, K4, SVCE 747987-001S 1

- ASSY, SWITCH AND BUTTON W/HARNESS, SVCE 748075-001S 1 3

- ASSY, CABLE FCC, AMP TO DSP, 95LG, 10-PIN 765531-001S 1

- ASSY, CABLE FCC, AMP TO DSP, 230LG, 10-PIN 765531-002S 1

- ASSY, CABLE FCC, AMP TO DSP, 190LG, 20-PIN 765532-001S 1

- ASSY, CABLE FCC, AMP TO DSP, 320LG, 20-PIN 765532-003S 1

- ASSY, CABLE FCC, R PNL TO DSP, 70LG, 20-PIN 765535-001S 2

- ASSY, HARNESS, DSP TO PS, 140LG, 6-PIN 765536-002S 1

- ASSY, HARNESS, AMP TO PS, DBL CONN, 3-PIN 765538-002S 1

- ASSY, CABLE, GROUND INLET 765540-001S 1 3

- ASSY, HARNESS, IEC TO SWITCH 765541-001S 1 3

- ASSY, CABLE, SWITCH TO PS 774336-001S 1 3
