Bose PowerShare PS602P Service Manual

89
ELECTRICAL PART LIST
Front Panel PCB Assembly, PS602P
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J900 WIRE-CONN, 10P, P2.0, #26, UL1007, L=415,
RD/WH, F/M
7013-4640
J901 BRACKET, GROUND, BRASS, T=0.8, TIN, PLATED 4132-6223
VR900 VR, ROTARY, 10KBX1, 10%, 21C, /, V, L=15 4751-2990
VR901 VR, ROTARY, 10KBX1, 10%, 21C, /, V, L=15 4751-2990
Front Panel PCB Assembly, PS604
Resistors
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C900 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C901 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C902 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C903 CC, 25V, 0.01uF, 10%, 0603, 0.8X1.6 150E-103KAC
C904 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
Reference
Designator
Description
V
endor Part
Number
Note
R900 RMG, 1/16W, 47 OHM, 1%, 0603 4723-470A
R901 RMG, 1/16W, 47 OHM, 1%, 0603 4723-470A
R904 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R905 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R906 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R907 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R908 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R909 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R910 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R911 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R912 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R913 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R914 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R915 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R916 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R917 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R918 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R919 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R921 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A
R922 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
